INTRODUCTION

Here’s the smart way of building your own robot, wheeler, windmill, plane, helicopter and airboat. You can save the expenses on replacing batteries. With this 6 in 1 solar kit, you can combine your knowledge as well as the practical ability and environmental protection by building 6 different models.

This DIY Solar Kit is easy enough for children to build, and they’ll be amazed watching them work purely by Solar Power.

ASSEMBLING OF SOLAR MODULE

HARDWARE REQUIRED

• Part P 1
• Part P 4
• Part D 22
• Part D 23
• Diagonal Cutter – 1 (Not Included in Kit)

ASSEMBLING

• First, you need to Wrap Off Part P 4 from both the sides and assemble it with Part D 22 as given in the image below.

• Now, uncover the Part P1 or Solar Panel and assemble it as shown in the image below.

• Place Part D 23 over the main body of the Solar Panel Module.

• Here’s the Finished Product

ASSEMBLING OF GEAR BOX A

HARDWARE REQUIRED

• Part P 3
• Part P 5
• Part D 20
• Part D 21
• Diagonal Cutter – 1 (Not Included in Kit)

ASSEMBLING

• Assemble the Part P 3 with the Part D 20 as shown in the image below.

• Assemble Part P 5 with the main body of Gear Box A as shown in the image below.

• Assemble the Part D 21 in such a way that wire comes out of the given hole as shown in the image below.

• Here’s the Finished Product

ASSEMBLING OF GEAR BOX B

HARDWARE REQUIRED

• Part P 2
• Part P 5
• Part D 20
• Part D 21
• Diagonal Cutter – 1 (Not Included in Kit)

ASSEMBLING

• Assemble the Part P 2 with the Part D 20 as shown in the image below.

• Assemble Part P 5 with the main body of Gear Box B as shown in the image below.

• Assemble the Part D 21 in such a way that wire comes out of the given hole as shown in the image below.

• Here’s the Finished Product

SOLAR ROBOT

HARDWARE REQUIRED

• Solar Module – 1
• Gear Box A – 1
• Part B 4 – 1
• Part B 12 – 1
• Part B 14 – 1
• Part B 15 – 1
• Part B 16 – 1
• Part D 29 – 1
• Part D 28 – 1
• Part D 30 – 1
• Part D 31 – 1

ASSEMBLING

• Attach Part B 4, B 16, D 28 and D 29 with the main body of the Solar Robot as shown in the image below.

• Attach Part D 30 with the D 31 as shown in image below and assemble it with the main body of the Solar Robot.

• First, attach Part B 14 (2 wheels) with the Gear Box A. Then, assemble Part B 12 and B 15 with the Bottom Part of the Solar Robot as shown in the image below.

• Assemble the Solar Module with the Main body of Solar Robot and attach the Top Part with the Bottom Part of the Solar Robot.

• Connect the two wires of the Gear Box A with the two terminals of Solar Module as shown in the image below. The wire should be connected in the appropriate manner to get the Robot in working state.

• Here’s the Finished Product after assembling of all the Parts and Solar Module.

NOTE: Do not touch the Solar Panel or surface of the Motor during or after the operation under strong sunlight.

Give the unit time to cool down after use, otherwise you may burn yourself.

SOLAR WHEELER

HARDWARE REQUIRED

• Solar Module – 1
• Gear Box A – 1
• Part B 4 – 1
• Part B 12 – 1
• Part B 13 – 1
• Part B 14 – 1

ASSEMBLING

• First, attach pair of wheels (Part B 14) with the Gear Box A as shown in the image below.

• Attach Part B 12 with the Part B 13. And then assemble them with the main body of the Solar Wheeler Robot.

• Attach Part B 4 with the main body as well as Solar Module and then assemble them with the Main body of Solar Wheeler Robot.

• Connect the two wires of the Gear Box A with two terminals of Solar Module as shown in image below. The wire should be connected in an appropriate manner for Robot functioning.

• Here’s the Finished Product after assembling of all the Parts and Solar Module.

NOTE: Do not touch the Solar Panel or surface of the Motor during or after the operation under strong sunlight.

Give the unit time to cool down after use, otherwise you may burn yourself.

SOLAR WINDMILL

HARDWARE REQUIRED

• Solar Module – 1
• Gear Box B – 1
• Part A 1 – 4
• Part B 2 – 1
• Part B 4 – 1
• Part B 17 – 3
• Part B 18 – 1
• Part C 24 – 1
• Part C 27 – 1
• Part D 32 – 1

ASSEMBLING

• First, attach Part D 32 with the Part C 27. Then, attach and insert Part C 27 with the Part C 24. Now, assemble all the four Parts of A 1 with the Part C 24 as shown in the image below.

• Attach Solar Module with the Part B 4 and B 2. And then attach the Parts of B 17 with the Part 18. Now, assemble both the parts with each other to form the main body of the Solar Windmill Robot.

• Connect the two wires of the Gear Box B with the two terminals of Solar Module as shown in the image below. The wire should be connected in the appropriate manner to get the Robot in working state.

• Here’s the Finished Product after assembling of all the Parts and Solar Module.

NOTE: Do not touch the Solar Panel or surface of the Motor during or after the operation under strong sunlight.

Give the unit time to cool down after use, otherwise you may burn yourself.

SOLAR PLANE

HARDWARE REQUIRED

• Solar Module – 1
• Gear Box B – 1
• Part A 1 – 4
• Part A 3 – 1
• Part A 5 – 1
• Part A 9 – 1
• Part A 10 – 1
• Part A 11 - 1
• Part C 24 – 1
• Part C 25 – 1
• Part C 27 – 1
• Coin (Not Included in the Kit) – 1

ASSEMBLING

• First, attach Part A 5 and A9 with the Part C 25. Then, attach and insert Part C 27 with the Part C 24 and C 25. Now, assemble all four Parts of A 1 with Part C 24 as shown in the image below. Connections must be made accurately for working of Solar Plane.

• Attach Solar Module with the Part B 4. And then attach the Parts B 2, A 3 and A 10 with Gear Box B. Now, assemble them with the remaining body of the Solar Plane. All the connections must be made according to the image given below.

• Connect the two wires of the Gear Box B with the two terminals of Solar Module as shown in the image below. The wire should be connected in an appropriate manner for Robot functioning.

• Insert the coin as shown in the image below.

• Now, adjust the solar module to balance the lever.

• Here’s the Finished Product after assembling of all the Parts and Solar Module.

NOTE: Do not touch the Solar Panel or surface of the Motor during or after the operation under strong sunlight.

Give the unit time to cool down after use, otherwise you may burn yourself.

SOLAR HELICOPTER

HARDWARE REQUIRED

• Solar Module – 1
• Gear Box B – 1
• Part A 1 – 4
• Part A 3 – 1
• Part A 5 – 1
• Part A 6 – 1
• Part A 7 – 1
• Part A 8 – 1
• Part B 4 - 1
• Part C 24 – 1
• Part C 25 – 1
• Part C 26 – 1
• Coin (Not Included in the Kit) – 1

ASSEMBLING

• First, attach Part A 5 and A 6 with Part C 25. Then, attach and insert Part C 26 with Part C 24 and C 25. Now, assemble all four Parts of A 1 with Part C 24 as shown in image below. Connections must be made accurately for working of Solar Plane.

• Attach Solar Module with the Part B 4. And then attach the Parts A 7, A 3 and A 8 with the Gear Box B. Now, assemble them with the remaining body of the Solar Helicopter. All the connections must be made according to image given below.

• Connect the two wires of the Gear Box B with the two terminals of Solar Module as shown in the image below. The wire should be connected in the appropriate manner to get the Robot in working state.

• Insert the coin as shown in the image below.

• Now, adjust the solar module to balance the lever.

• Here’s the Finished Product after assembling of all the Parts and Solar Module.

NOTE: Do not touch the Solar Panel or surface of the Motor during or after the operation under strong sunlight.

Give the unit time to cool down after use, otherwise you may burn yourself.

SOLAR AIRBOAT

HARDWARE REQUIRED

• Solar Module – 1
• Gear Box B – 1
• Part A 1 – 4
• Part A 3 – 1
• Part B 4 – 1
• Part B 2 - 1
• Part C 19 – 1

ASSEMBLING

• First, adjoin the four Parts of A 1. Then, attach and insert Part C 19 with the Part A 1. Now, assemble them as shown in the image below. Connections must be made accurately for working of Solar Airboat.

• Attach Solar Module with the Part B 4. And then attach the Parts B 2 and B 4 and A 3 with the Gear Box B. Now, assemble them with the remaining body of the Solar Airboat. All the connections must be made according to the image given below.

• Connect the two wires of the Gear Box B with the two terminals of Solar Module as shown in the image below. The wire should be connected in the appropriate manner to get the Robot in working state.

• Here’s the Finished Product after assembling of all the Parts and Solar Module.

NOTE: Do not touch the Solar Panel or surface of the Motor during or after the operation under strong sunlight.

Give the unit time to cool down after use, otherwise you may burn yourself.
