YDLIDAR TEA Lidar Sensor 360° 2D Laser Range Finder For Robotics & SLAM For High Precision Lidar For Mapping & Navigation
YDLIDAR TEA Lidar Sensor 360° 2D Laser Range Finder For Robotics & SLAM For High Precision Lidar For Mapping & Navigation
SKU:
In stock
Couldn't load pickup availability
- For Bulk Order Click Here
- Need Customer Support?
- Free Delivery Above 999/-
For refund/return/replacement, call us at +91 95995 94520 , +91 95991 22209 or mail us at support@rees52.com
Delivery Time
Delivery Time
- Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.
- Delivery time if the order item is on Preorder Status is 15-20 working days.
COD (Cash on Delivery)
COD (Cash on Delivery)
- For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
Description:
The YDLIDAR TEA is a high-performance 2D LiDAR sensor designed for outdoor applications. Utilizing Time-of-Flight (ToF) technology and a single-line scanning design, it captures 30,000 point cloud data points per second. The TEA employs a 905nm infrared excitation light and a proprietary signal processing algorithm for robust outdoor performance. With an IP65 dustproof and waterproof rating and an industrial network interface, it's easily integrated into various systems for robot navigation, obstacle avoidance, environmental mapping, industrial AGVs, and assisted driving.
Specifications:
- Model Type: LiDAR Sensor
- Field of View: 270Deg
- Supply Voltage: 12V
- Operating Power: 2W
- Wavelength: (LASER) 905
- Protection Standard: IP65
- Ranging Frequency: 30000 Hz
- Scanning Frequency: 20 Hz
- Angular Resolution: 0.24°
Features:
- 30kHz high-speed range frequency
- High-precision, consistent ranging
- 300° horizontal field of view
- Configurable up to 30Hz scanning frequency
- Strong ambient light resistance
- IP65 dustproof waterproof
- 100M adaptive network interface for data
Applications:
- Robot navigation and obstacle avoidance
- Industrial automation
- Regional security
- Smart Transportation
- Environmental scanning and 3D reconstruction
- Digital multimedia interaction
- Robot ROS teaching and research
Package Included:
1 x YDLIDAR TEA
