Description:
Waveshare OV5693 Camera Module is a 5MP USB Camera board module used for boards with USB input on development boards. It also expands the capabilities of your microcontroller thanks to its ability to take pictures, flash, and record audio and video.
It features a high-resolution OV5693 image sensor capable of capturing images with a resolution of up to 5 megapixels (2592 x 1944 pixels), ensuring excellent image quality.
Specifications:
- Item Type: USB Camera
- Pixel: 5MP
- Sensor: OV5693
- Interface: USB 2.0
- Sensor size: 1/4 inch
- Aperture (F): 2.1
- Focal length (EFL): 2.5 mm
- Field of view (FOV): 135°(D) 95°(H) 70°(V)
- Focus: Auto-focusing
- Format support: MJPG, YVY2
- Static image resolution: 2592 × 1944
- Video recording MJPG: 2592 × 1944 15FPS 1920 × 1080 15FPS 1280 × 720 15FPS 640 × 480 15FPS YUY2: 2592 × 1944 3FPS 1920 × 1080 5FPS 1280 × 720 10FPS 640 × 480 15FPS
- Operating Voltage: 5V ± 5%
- Operating Current: 500mA
- Camera size: 18.00 × 18.00 × 19.69 mm
Package Included:
1 x Waveshare OV5693 Camera Module 5MP USB Camera Module High-Resolution USB Camera Fixed-Focus, Auto Focusing, M12 Camera Module 135° Wide View USB 2.0 Webcam Board Support Video Recording For Video System Security System
