Waveshare Infrared Reflective Sensor Adjustable Obstacle & Line Following Module for Arduino & Raspberry Pi
Waveshare Infrared Reflective Sensor Adjustable Obstacle & Line Following Module for Arduino & Raspberry Pi
SKU:
In stock
Couldn't load pickup availability
- For Bulk Order Click Here
- Need Customer Support?
- Free Delivery Above 999/-
For refund/return/replacement, call us at +91 95995 94520 , +91 95991 22209 or mail us at support@rees52.com
Delivery Time
Delivery Time
- Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.
- Delivery time if the order item is on Preorder Status is 15-20 working days.
COD (Cash on Delivery)
COD (Cash on Delivery)
- For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
Description:
The Waveshare Infrared Reflective Sensor Module is a compact IR-based sensor that detects objects within a 0–30 mm range. It features both digital and analog outputs and operates at 3V to 5.3V, making it ideal for obstacle detection, line tracking, and proximity sensing applications.
The module includes an infrared transmitter and receiver. The transmitter emits IR light (830–950nm), while the receiver detects the reflected signal and converts it into an electrical output. Its efficient design ensures reliable performance in low-power embedded systems, robotics, and DIY electronics.
Specification:
- Power: 3.0V ~ 5.3V
- Dimension: 25mm * 15.9mm
- Mounting hole size: 2.0mm
Features:
- Reflective Infrared Transceiver
- Features a wide-range voltage comparator LM393
- Adjustable sensitivity
- Signal output indicator
Useful Link:
Waveshare Infrared Reflective Sensor Module
Package Included:
- 1 x Infrared Reflective Sensor
- 1 x 4-pin custom connector jumper wire
