Waveshare ESP32-C6 Mini Development Board Dual-Core 160MHz WiFi 6 & BT5 Development Board Based on ESP32-C6FH4, Without Header

Description:

The Waveshare ESP32-C6 Mini Development Board. This compact, high-performance board, powered by the ESP32-C6FH4 (ESP32-C6-MINI-1) chip, features a 160MHz RISC-V 32-bit single-core processor. It's packed with 320KB ROM, 512KB HP SRAM, 16KB LP SRAM, and 4MB Flash. Experience cutting-edge wireless connectivity with 2.4GHz WiFi 6 and Bluetooth 5. Its Raspberry Pi Pico pin headers ensure broad compatibility with peripherals, making development seamless. Jumpstart your applications effortlessly using ESP-IDF or Arduino.

Specification:

• Processor: 32-bit RISC-V
• ROM: 320KB
• SRAM: 512KB
• Flash memory: 4MB
• USB:  Type-C

Features:

• Equipped with a high-performance 32-bit RISC-V processor with a clock speed up to 160 MHz, and a low-power 32-bit RISC-V processor with a clock speed up to 20 MHz.
• Built in 320KB ROM, 512KB of HP SRAM, 16KB LP SRAM, and 4MB Flash memory.
• Integrated 2.4GHz Wi-Fi and Bluetooth LE dual-mode wireless communication, with superior RF performance.
• Castellated module and onboard ceramic antenna allow soldering directly to carrier boards.
• Supports flexible clock, module power supply independent setting, and other controls to realize low power consumption in different scenarios.
• Onboard USB Type-C port, 22 × GPIO pins allow flexible configuration of pin functions.

Product Interface:

1. ESP32-C6FH4-Built-in dual processors, main frequency is up to 160MHz.
2. USB Type-C Part- for downloading the programme and debugging.
3. ME6217C33M5G- low dropout LDO, 800mA (Max).

4. WS2812 RGB LED.
5. 2.4G ceramic antenna
6. BOOT Button- press it and then press the reset button to enter download mode.
7. Reset Button
8. ESP32-C6FH4 pins.

Pin Description:

Useful Link:

Waveshare ESP32-C6 Mini Dev Board

Package Included:

1 x Waveshare ESP32-C6 Mini Dev Board Without Soldered
