Waveshare 240×135, General 1.14inch LCD Display Module, IPS, 65K RGB - RS2417

Waveshare 240×135, General 1.14inch LCD Display Module, IPS, 65K RGB - RS2417

SKU:RS2417

Regular price Rs. 623.00
Regular price Sale price Rs. 623.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94524 For bulk and B2B enquiries kindly mail us at support@rees52.com

  • Fast Shipping
  • Affordable Price
  • Support
View full details
  • Operating voltage: 3.3V/5V (Please ensure that the power supply voltage and logic voltage are consistent, otherwise it will not work properly)
  • Interface: SPI
  • LCD type: IPS
  • Controller: ST7789
  • Resolution: 135(H)RGB x 240(V)
  • Display area: 14.864(H)x 24.912(V)mm
  • Pixel size: 0.1101(H)x 0.1035(V)mm
  • Dimension: 35(H) x 32(V) mm

Description :

This product provides Raspberry Pi, STM32, arduino examples

Specification

  • Operating voltage: 3.3V/5V (Please ensure that the power supply voltage and logic voltage are consistent, otherwise it will not work properly)
  • Interface: SPI
  • LCD type: IPS
  • Controller: ST7789
  • Resolution: 135(H)RGB x 240(V)
  • Display area: 14.864(H)x 24.912(V)mm
  • Pixel size: 0.1101(H)x 0.1035(V)mm
  • Dimension: 35(H) x 32(V) mm

Features :

  • 240×135 resolution, 65K RGB colors, clear and colorful displaying effect
  • SPI interface, minimizes required IO pins, supports controller boards like Raspberry Pi/Arduino/STM32
  • Comes with development resources (examples for Raspberry Pi/Arduino/STM32)

Package Included :

  • 1.14inch LCD Module x1
  • PH2.0 8PIN 20cm cable x1
