- OPERATING VOLTAGE : 5V
- RESOLUTION : 320×240 pixels
- COMMUNICATION INTERFACE : SPI
- DISPLAY SIZE : 57.60 × 43.20 mm
- DISPLAY PANEL : IPS
- PIXEL SIZE : 0.18 × 0.18 mm
- DRIVER : ST7789
- DIMENSIONS : 70.20 × 50.20 mm
- TOUCH CONTROLLER : XPT2046
Features :
- 320×240 resolution, IPS screen, 262K colors, clear and colorful displaying effect
- Dedicated touch controller, bringing more smooth touching effect than AD-controlled solutions
- MicroSD card slot for storing images and direct displaying them easily
- Programmable backlight control, power saving
- Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
Specifications :
- OPERATING VOLTAGE : 5V
- RESOLUTION : 320×240 pixels
- COMMUNICATION INTERFACE : SPI
- DISPLAY SIZE : 57.60 × 43.20 mm
- DISPLAY PANEL : IPS
- PIXEL SIZE : 0.18 × 0.18 mm
- DRIVER : ST7789
- DIMENSIONS : 70.20 × 50.20 mm
- TOUCH CONTROLLER : XPT2046
Package Included :
1 X 2.8inch Touch Display Module
