Waveshare 2.13-inch Touch E-Ink Display 250x122 High-Resolution E-Paper with ABS Protective Case for Raspberry Pi Zero

Waveshare 2.13-inch Touch E-Ink Display 250x122 High-Resolution E-Paper with ABS Protective Case for Raspberry Pi Zero

SKU:

In stock

Regular price Rs. 1,750.00
Regular price Sale price Rs. 1,750.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94520 , +91 95991 22209 or mail us at support@rees52.com

Delivery Time

  • Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.

  • Delivery time if the order item is on Preorder Status is 15-20 working days.

COD (Cash on Delivery)

  • For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
View full details

Description:

This 2.13-inch Waveshare E-Ink Touch Display is designed for the Raspberry Pi Zero series, offering a crisp 250×122 resolution with black and white display support. Featuring an embedded controller and SPI interface, it ensures seamless integration with Raspberry Pi, Arduino, Nucleo, and other microcontroller platforms. With no backlight, the screen can retain content even without power, making it ideal for ultra-low-power applications. It refreshes only when needed, ensuring energy efficiency, while providing excellent sunlight readability and a wide viewing angle—perfect for outdoor or portable projects. Comes housed in a durable ABS case.

Specification:

  • Operating voltage: 3.3V
  • Interface: 3-wire SPI, 4-wire SPI
  • Outline dimensions: 69.15 x 38.90mm
  • Display size: 48.55 xv23.70mm
  • Dot pitch: 0.194 x 0.194mm
  • Resolution: 250×122 pixels
  • Display color: black, white
  • Grey scale: 2
  • Partial refresh time: 0.3s
  • Full refresh time: 2s
  • Refresh power: 26.4mW(typ.)
  • Standby current: 0.01uA (almost none)
  • Viewing angle: 170°
  • Touch point: 5 (max)

Features:

  • 2.13" capacitive touch e-Paper display, 5-point touch, 250×122 pixels
  • Supports waking up by user-defined gesture
  • No backlight, keeps displaying the last content for a long time even when powered down
  • Ultra-low power consumption is only required for refreshing
  • Standard Raspberry Pi 40-PIN GPIO extension header, supportsRaspberry Pi Zero Series
  • Comes with development resources and manual (examples for Raspberry Pi)

Product Interface:

Pin Description:

Useful Link:

Waveshare 2.13" Touch E-Paper Display for Raspberry Pi Zero

Package Included:

  • 1 x 2.13-inch Touch e-Paper HAT
  • 1 x ABS case
  • 1 x Screwdriver
  • 1 x Thermal tape
  • 1 x rubber feet 4PCS
  • 2 x Screws
