Description:
The UltraPower UP-S4AC Smart Charger is a compact yet powerful charging solution designed for multi-battery users. It features four independent channels, each delivering up to 7W, allowing you to charge up to four 1–2S LiPo/LiHV or 2–6S NiMH/NiCd batteries simultaneously with precision. With adjustable charging current from 0.1A to 1.0A, it provides flexibility for various battery types. The clear LCD shows key charging information such as battery type, cell voltage, charge current, and capacity, ensuring real-time monitoring. Built-in safety features include reverse polarity protection, battery over-voltage protection, and reverse voltage protection, making the UP-S4AC a safe and reliable charger for everyday hobby or professional use.
Specifications:
- Input Voltage: AC 100-240V, DC 7.0-17.0V
- Charge Power: Max 7Wx4, ±10%
- Charge current: (0.1-1.0A)X4 , ±10%
- Battery Type: LiPo/LiHV/NiMH/NiCd
- Battery Cell count: LiPo/LiHV(1-2 cell) NiMH/NiCd(2-6
cell)
- Indication: LCD screen, LED light
- Support Battery Port: SM/XH/Micro/MX/JST/mCPX
Features:
- 4 independent charging ports
- 6 battery connectors per port
- Supports 1–2S LiPo/LiHV 2–6S NiMH/NiCd
- LCD, LED, and sound status indicators
- Adjustable current up to 1.0A per port
Package Included:
1 x UltraPower UP-S4AC 4-Port Smart Battery Charger
