Description:
TMC2100, a complete micro-stepping driver featuring an integrated encoder. This advanced module offers onboard micro-stepping management, resulting in significantly increased precision and remarkably reduced motor noise. While pinout and VREF differ from popular drivers like the A4988 and DRV8825, its enhanced performance makes it a compelling upgrade. Crucially, consult the datasheet carefully before installation and use.
Specifications:
- Model No.: TMC2100
- Model Series: TMC Series
- Voltage Rating: 5.5 to 46V
- Current Rating: 1.25 to 2.5A
Features:
- Adjustable Drive Current: Set via Vref (default 0.5A, max 1A).
- Vref Measurement: Check voltage between Gnd and potentiometer center.
- Measure Voltage Safely: Disconnect the motor before measuring voltage to prevent damage.
- Powered Measurement: Ensure board power is ON (not just USB) when measuring.
- Important: Correct Orientation: Install TMC2100 drivers in the proper direction on the board.
Package Included:
1 x TMC2100 Stepper Motor Driver Module
