Description:
TF02-pro is greatly upgraded and optimized based on TF02, with ranging performance up to 40m, a more efficient optical system, and better circuit design, while ensuring higher ranging performance, blind zone, and power consumption have excellent performance. With the optimization of the algorithm, the error performance in different environments is also improved significantly. Currently, TF02-Pro has been widely used in fields such as drone altitude holding, intelligent transportation, smart parking lots, and smart agriculture.
Specifications:
- Model: TF02-Pro LIDAR
- Type: LIDAR Distance Sensor
- Field of View (FOV): 3Deg.
- Distance Measuring Range(M): 0.3 to 40
- Avg. Power Consumption (W): ≤1W
- Avg. Current Consumption: ≤200mA
- Operating Voltage (V): DC 5V~12V
- Accuracy: ±5cm（0.05~5m），±1%（5~40m）
- Communication Interface: UART/I2C
- Frame Rate(Hz): 100Hz
- Protection Standard: IP65
- Peak Current(mA): 300
Features:
- The range is up to 40 meters.
- Ambient light resistance(Up to 100Klux)
- High frame rate(up to 1000Hz)
- Low power consumption.
- Wide range of temperature adaptation and voltage input.
- Has higher Accuracy and frequency.
- Richer Interface – UART/I2C/IO.
Applications:
- Intelligent traffic.
- Intelligent parking lots.
- Material level monitoring.
- UAV.
- Vehicle detection for barrier gate control.
- Robots outdoor obstacle avoidance.
- Vehicle position sensing.
Package Included:
1 x TF02-Pro 40M LIDAR Distance Ranging Sensor High-Precision LIDAR Sensor IP65 Rated LIDAR Sensor For Drones, UAVs, UAS and Robots
