Description:
The TEC1-12712 40x40mm Thermoelectric Cooler 12A Peltier Module offers a fascinating and practical demonstration of the Peltier Thermoelectric Effect. This compact module, measuring 40mm x 40mm, houses 127 meticulously arranged semiconductor couples, enabling it to efficiently cool or heat objects up to a substantial 80°C. This dual functionality makes it incredibly versatile for a range of applications.
Thermoelectric coolers, also commonly known as TECs or Peltier Modules, operate by creating a temperature difference between their two sides. When a current is applied, one side of the module becomes noticeably hot, while the opposite side simultaneously cools down. This characteristic allows them to be used for targeted heating or cooling, simply by utilizing the appropriate side. Furthermore, the temperature differential can even be harnessed to generate small amounts of electricity, opening up possibilities for energy harvesting.
Specifications:
- Model number: TEC1-12712
- Item Type: Thermoelectric Cooler
- Operating Voltage: 12V
- Maximum Voltage- Umax: 15V
- Maximum Current- Imax: 10A
- Maximum Power: 120W
- Power Cord: 25cm
Features:
- Small module.
- Easy transition between the hot side to the cool side and vice versa, just by reversing the polarity of the supply.
- Quality-tested cooling cells.
- Solid-state, vibration-free, noise-free.
- Simple to install and operate.
- Should use it with a heat sink.
Operating Tips:
- Do not exceed Imax or Vmax when operating a module.
- Please carry out moisture protection options (sealing) in final application use.
- Life expectancy: 200,000 hours
- Failure rate based on long-time testing: 0.2%.
Package Included:
1 x TEC1-12712 40x40mm Thermoelectric Cooler 12A Peltier Module
