Description:
35A Electronic Speed Controller (ESC):
This is Electronic Speed Controller (ESC) for car. High power system for RC model is very dangerous, so please read this manual carefully.
Since we can't control over the correct use, installation, application, or maintenance of our products, we'veno liability shall be assumed nor accepted for any damages,
losses or costs resulting from the use of the product. Any claimsarising from the operating, failure of malfunctioning etc. will be denied.
We assume no liability for personal injury,consequential damages resulting from our product or our workmanship.
2845 Brushless Motor:
This high-torque motor boasts a compact 28mm diameter and powerful 800W output. Available in a wide range of KV ratings (2600KV-5000KV), you can customize speed and power to suit your RC vehicle. Featuring 4 rotor poles for smooth operation and a robust construction, this motor is built to withstand the demands of high-performance racing.
Specifications:
35A Electronic Speed Controller (ESC):
- Brand: SURPASSHOBBY
- Name: KK 35A ESC
- Cont.Current/Burst Current: 35A/120A
- Motor Type: Sensorless Brushless Motor
- for 2S Lipo or 6 cells NiMH :
- on-road: 28XX-Size or smaller motor with the KV<6000KV
- off-road/Buggy/Monster: 28XX-size or smaller motor with the KV <4000KV
- for 3S Lipo or 9 cells NiMH :
- on-road: 28XX-Size or smaller motor with the KV<4000KV
- off-road/Buggy/Monster: 28XX-size or smaller motor with the KV <3000KV
2845 Brushless Motor:
- Brand: SURPASSHOBBY
- Series: KK
- Name: 2845 RC Motor
- Color: red
- KV(RPM/Volt): 2600KV/2800KV/3100KV/3800KV/4000KV/4400KV/5000KV
- Watt:800
- Max RPM: 50000
- Max voltage: <14V
- Max amps: 57A
- Rotor poles: 4
- Diameter: 28mm
- Length: 46.5mm
- Shaft: 3.175mm
- Shaft length: 15mm
- Connector: 3.5mm gold
- Weight:118g
Features:
35A Electronic Speed Controller (ESC):
- Water- proof and dust-proof for all-weather races; (Note: please uninstall the cooling fan before using this ESC in water;Clean and dry it soon after the use for avoiding the connectors get rusty.)
- Specially designed for RC car with excellent start-up, acceleration and linearity features.
- Compatible with sensorless brushless motor.
- The strong resistant current capability, excellent heat dissipation.
- Multiple protection features: Low voltage cut-off protection for litium or nickel battery /Over-heat protectionThrote signal loss protection / Motor blocked protection/
- Easily programmed and compatible with pocket-sized program card.
2845 Brushless Motor:
- 4 Pole 12 Slot Hi-torque Motor Design.
- High Quality: CNC Machined 6061 T6 Billet Aluminum Heatsink Can, High Purity Copper Windings maximize efficiency, High RPM ABEC5 Oversized Bearings.
- Universal fit, for all 1/12 2S RC car and 3S racing car.
- Precision balanced rotor,smoothness for best reliability and maximum RPM.
- Stator - Super Thin (0.35mm) Laminations.
- Removable/Replaceable rotor
- Precision Engineered for maximum Energy Conversion
Package Included:
- 1 x Electronic Speed Controller (ESC)
- 1 x Brushless Motor
