Description:
The A8 mini gimbal camera is equipped with a Neutral Network Processing Unit (NPU) built into the latest AI algorithms developed by SIYI. It can be used to identify vehicles such as boats and people. Combined with the gimbal rotation and UAV flight control system, the gimbal camera provides an overall smart operation, from identification and locating to continuous tracking.
The A8 mini zoom camera will always keep tracking objects in the center of the image. The AI function is currently in development and will be supported with firmware updates.
Specifications:
- Video output signal interface: Ethernet port, Micro-HDMI, CVBS (AV) | Control signal input method: S.Bus, UART, UDP
- Control signal output mode: S.Bus
- Operating voltage range: 11~16.8V
- Power consumption: Average power consumption: 5W, Peak
- power consumption: 12W
- Operating environment temperature: -10° to 50°C
- Angle Blurring Range: ±0.01°
- Controllable Pitch Rotation Range: -135° to +45°
- Controllable Horizontal Rotation Range: -160° to +160°
- Rolling Range: -30°
- Focal Length: 21mm
- Image Sensor: Sony 1/1.7" CMOS Effective 8 Million Pixels
- Aperture: F2.8
Features:
- The 1/1.7" ultra-sensitive starlight CMOS of A8 mini camcorders can keep the image bright even in dark environments.
- The HDR function accurately captures the highlights and shadow details of dynamic scenes to avoid low or backlight
- AI Smart ID Tracking 1/1.7" Sony CMOS4K Ultra HD Photo & Video Recording 6X Digital Zoom Upside Down Mode Star Light Night Vision Camera
Camera Typical Connection Diagram:
Pin Description:
Useful Links:
Package Included:
1 x SIYI A8 Mini 3-Axis 4K Gimbal Camera SIYI A8 Mini Gimbal Camera Ultra HD 6X Digital Zoom SIYI A8 Mini 4K 8MP Gimbal Elevate Your Aerial Photography With SIYI A8 Mini For UAV, UGV, USV, RC Planes, And FPV Drones
