Description:
This robust RS485 vibration sensor operates on a wide 10-30V DC power supply, making it adaptable to various setups. Built for challenging environments, it's waterproof and dustproof, withstanding dry, humid, and noisy conditions. Data transmission via RS485 ensures signal integrity and stable communication. Available in single-axis or tri-axis configurations.
Specifications:
- Power supply: DC10-30V
- Model: RS-WZ3/WZ1-*-1-EX
- Frequency range: 10-1600Hz
- Working environment: -40℃~+80℃, 0%RH~80%RH
- Vibration speed range: 0-50mm/s
- Vibration velocity accuracy: ±1.5% FS (@1kHz, 10mm/s)
- Vibration velocity resolution: 0.1mm/s
- Vibration displacement range: 0-5000μm
- Vibration displacement resolution: 0.1μm
- Surface temperature range: -40~+80℃
- Temperature display resolution: 0.1°C
Features:
- The protection grade is IP67. The shell is 304 stainless steel, small and durable. This IoT vibration sensor can be used in many environments.
- Can measure X, Y, and Z three-axis speed. The vibration speed range is 0-5000μm, whether it is 0-100μm, 0-200μm, 0-1000μm equipment, or 0-2000μm equipment, all ok.
- Installing industrial vibration sensors at different measuring points, the vibration signals and temperature changes of the equipment can be measured. Then upload it to the data platform, and users can grasp the equipment status anytime and anywhere.
- Users can filter by time in the historical data in the platform at any time, and quickly query the required data. It is also possible to convert the data into monthly reports and weekly reports, and export and print them in forms/polylines.
Package Included:
1 x Renke RS-WZ3-N01-1-CX Industrial Vibration Sensor
