Readytosky 80A 2-6S Brushless ESC 2-6S Brushless Electronic Speed Controller (ESC) High Power 80A ESC For FPV Racing Drones and Quadcopters - RS2925

Readytosky 80A 2-6S Brushless ESC 2-6S Brushless Electronic Speed Controller (ESC) High Power 80A ESC For FPV Racing Drones and Quadcopters - RS2925

RS2925

28 in stock

Rs. 1,642.00
Rs. 1,642.00
Sale Sold out
Shipping calculated at checkout.

Note: In case you receive a damaged or faulty product, please return it in the original box with all foam and packaging. Returns will not be accepted if further damage occurs due to improper packing.

For refund/return/replacement, call us at +91 95991 22209 or mail us at support@rees52.com

Delivery Time

  • Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.

  • Delivery time if the order item is on Preorder Status is 15-20 working days.

COD (Cash on Delivery)

  • For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
View full details

Description:

Readytosky 80A 2-6S Brushless ESC comes with a multi-integrated special program, fast throttle response, and surpasses all kinds of open-source software. Firmware was optimized specifically integrated circuitously for the disc motor, and it has very good compatibility this ESC is compatible with 2-6s Lipo Battery.

2-6S Brushless Electronic Speed Controller is specifically made for quadcopters and multi-rotors. Which provides faster and better motor speed control giving better flight performance compared to other available ESCs. Due to ultra-low resistance MOSFET, it has a strong flow capacity. With the MOSFET special driver integrated circuit, its performance and stability far surpass the driving circuit with discrete components built.

Specifications:

  • Model: 80A Brushless ESC
  • Burst Current: 100A
  • Constant Current: 80A
  • BEC: Yes (5V/5A)
  • Compatible Lipo Batteries: 2 ~ 6S
  • Throttle Signal Refresh Rate: 50 ~ 432Hz
  • Maximum Speed: 210000 2-pole motor rev / min, 6-pole motors 70,000 rev / min, 12 pole motors 35,000 rev / min
  • Colour: Black

Features:

  • Security power function: When the power is turned on, regardless of the throttle stick at any position will not start the motor immediately to prevent personal injury;
  • Throttle range calibrated function: to adapt the throttle differences between different strokes, and improve the linearity of throttle response.
  • programmed project (available throttle stick or card LED parameter settings):
  • Brake setting: No brake / with brake.
  • Battery Type: Lithium battery / NiMH.
  • Low Voltage Protection Mode: Soft Shutdown / hard off.
  • Low Voltage Protection Threshold: low/medium/high.
  • start mode: Normal / Soft / Super-soft and start.
  • Timing: low/medium/high.
  • Restore factory defaults.
  • Comprehensive protection features:
  • Under-voltage protection: the program set by the user when the battery voltage is below the protection threshold, ESC automatically reduces the output power;
  • Overvoltage Protection: input voltage exceeds the input range is not allowed to start, automatic protection, also issued a hasty “beep” Warning ;
  • Overheat protection: built-in temperature detection circuit that automatically reduces the output power ESC temperature is too high;
  • Remote signal loss protection: The remote control signal is lost for 1 second to reduce the power, and then has two seconds to turn off without the remote control signal output.

Package Included:

1 x Readytosky 80A 2-6S Brushless ESC 2-6S Brushless Electronic Speed Controller (ESC)
