Description:
Raspberry Pi 5 builds on the phenomenal success of Raspberry Pi 4. Featuring a 64-bit quad-core Arm Cortex-A76 processor running at 2.4GHz, Raspberry Pi 5 delivers a 2–3× increase in CPU performance relative to Raspberry Pi 4. Alongside a substantial uplift in graphics performance from an 800MHz VideoCore VII GPU. Other enhancements include improvements to camera i/o, display, and USB interfacing (Aggregate USB bandwidth is more than doubled). The Raspberry Pi 5 delivers a smoother desktop experience and performance that opens the door to new applications for industrial customers.
These interfacing improvements are delivered by the RP1 I/O controller chip, designed in-house at Raspberry Pi. For the first time, there is Raspberry Pi silicon on a flagship product! The Raspberry Pi 5 is a quad-core computer that can drive 2 x 4k monitors, LPDDR4X-4267 SDRAM, Gigabit Ethernet, with PoE+ support, USB3.0, wireless LAN, Bluetooth 5.0, and more! It has all of the specs and the raw performance normally found on desktop PCs. The Raspberry Pi 5 is currently available in both 4BG & 8GB versions. For the first time, the Pi now features its own onboard on/off switch.
The new Raspberry Pi 5 offers the perfect coding environment for all ability levels and there are plenty of guides online for any kind of project you can imagine. Raspberry Pi 5 has onboard connectivity; Wifi, USB2.0/3.0, Gigabit Ethernet, and Bluetooth give you all of the networking options you could possibly want. The 40-pin GPIO connectors mean that you can expand the board via HATs and connect a whole array of extra devices.
The Raspberry Pi 5 is 100% ready for education, it offers the perfect platform for learning and teaching; coding, Linux, IoT systems, streaming media, playing games, automated domestic and industrial applications, a complete desktop solution, and much much more.
Specifications:
- CPU: 2.4GHz quad-core, 64-bit Arm Cortex-A76, with 512KB L2 cache and a 2MB shared L3 cache.
- GPU: 800MHz VideoCore VII GPU supporting OpenGL ES 3.1, Vulkan 1.2.
- RAM: LPDDR4X-4267 SDRAM (4GB or 8GB).
- WiFi: Dual band 2.4 GHz and 5.0 GHz 802.11ac Wi-Fi.
- Bluetooth: Bluetooth 5.0 / Bluetooth Low Energy (BLE).
- Storage: Micro SD card slot, with support for high-speed SDR104 mode.
- USB 3.0: 2 x USB 3.0 ports, supporting simultaneous 5Gbps operation.
- USB 2.0: 2 x USB 3.0 ports.
- Ethernet: Gigabit Ethernet, with PoE+ support (requires PoE+ HAT).
- HDMI: 2 x micro-HDMI® ports (up to 4kp60 supported) HEVC decoder and HDR support.
- DSI/CSI: 2 × 4 lane MIPI camera/display transceivers (3x bandwidth improvement).
- PCle: PCIe 2.0 x1 interface for fast peripherals (requires separate M.2 HAT or other adapter).
- Power: 5V/5A DC power via USB-C, with Power Delivery support.
- GPIO: Raspberry Pi standard 40-pin header (Backwards compatible).
- RTC: Real-Time Clock (RTC), powered by an external battery.
- On/Off Switch: On-board power button
Features:
- The Raspberry Pi 5 is the latest model of everyone's favourite single-board computer.
- The Raspberry Pi 5 sees significant upgrades and speed increases (2-3x in CPU performance) over its predecessor, the Raspberry Pi 4 Model B. A full feature comparison can be found here.
- The Raspberry Pi 5 board is available in both 4GB and 8GB versions.
- It offers performance that rivals entry-level PCs at a fraction of the cost.
- The Raspberry Pi 5 offers the perfect platform for learning/teaching; coding, Linux, IoT systems, streaming media, playing games, automated domestic and industrial applications, or your complete desktop solution and much more.
- It is the first time the flagship product has features Raspberry Pi silicon, the RP1 I/O controller chip has been designed in-house at Raspberry Pi HQ.
- Each board will include a marking on the upper side of the PCB to identify what memory density is fitted to a specific board.
- All boards now carry a unique serial number on the PCB.
Package Included:
1 x Raspberry Pi 5 Single Board Computer with 2.4GHz quad-core, 64-bit Arm Cortex-A76, and LPDDR4X-4267 SDRAM 2GB, 4GB, 8GB
