Premium Toolless FTP 180° Keystone Jack With Internal Flip Shutter For Quick Network Setup

Description:

Crafted with durable zinc alloy for the plastic components, this solution enhances longevity. The inclusion of a standard 110 and LSA dual-use punching tool streamlines installation, offering exceptional operational convenience. Engineered for dependable cable connections, the IDC clips feature a thoughtful 180-degree angled design.

Adhering rigorously to ISO/IEC 11801 and TIA/EIA 568-B.2 Cat.6 standards ensure optimal performance. Internally, gold-plated pins, IDC clips, and a meticulously designed PCB board work in harmony to deliver superior signal integrity. To prevent oxidation and extend service life, the entire pin structure is nickel-plated, with the contact pins featuring a substantial 6μ gold plating. The tinned phosphor bronze IDC clips, further enhanced with nickel plating, guarantee a robust and reliable connection, tested to withstand at least 250 terminations.

Specifications:

• Model Number: HKJ-803FM-D03

• Material: zinc alloy

• gold plated: 3u"-50u"

Electrical Characteristics

• DC Resistance: ≤300mΩ

• Contact Resistance: ≤20mΩ

• Dielectric strength: 1000V(AC750V)1min

• Insulation Resistance: ≥1000MΩ

Physical Characteristics

• Phosphor bronze with nickel-plated, connector pins with golden plated 6μ
• IDC clip: Tinned phosphor bronze pins with nickel plated, fitting for 22- 26AWG cables
• Inserting Duration: ≥750 times
• Punching Duration: ≥250 times
• Jack housing plastic part: UL 94V-0, RED, YELLOW, BLUE, GREEN, BLACK, and other colors available
• Termination caps material UL94V-0
• Working temperature: -25ºC~60ºC

Features:

• Features zinc alloy plastic parts for enhanced longevity.
• Includes a dual-use 110/LSA punch tool for quick and easy installation.
• 180-degree angled IDC clips ensure reliable cable retention.
• Meets ISO/IEC 11801 and TIA/EIA 568-B.2 Cat.6 standards.
• Gold-plated pins, IDC clips, and PCB ensure superior performance.
• Nickel-plated pins with 6μ gold plating prevent oxidation, extending lifespan.
• Tinned phosphor bronze IDC clips are nickel-plated for over 250 reliable connections.

Schematic:

Applications:

• Network
• Structured cabling transmits data, voice, and video
• Applied for Cat. 6 and E Classes
• Suitable for working area, central room, managing room, equipment room, and subsystem applications

Standards:

• ISO/IEC11801
• TIA/EIA-568B.2-1
• EN50173
• UL 94V-0

Package Included:

1 x Premium Toolless FTP 180° Keystone Jack With Internal Flip Shutter
