- Micro USB input: 5V 1A
- USB Output: 5V 2.1A / 5V 1A(Dual USB interface)
- Charging display: intelligent digital display
- Batteries Type: liquid lithium-ion batteries (18650)
Description:
This is the mobile power module Accessories, 18650 Circuit board shell. Meet the individual needs of your DIY, but you must understand basic electronic assembly. The circuit board is connected to the battery negative B-, B + is positive, do not connect reversed, connecting reversed will burn the board, the battery is connected in parallel welding, and assembling battery. Note that the insulation between the battery and the circuit board, battery lead not to touch the circuit board, so as not to cause a short circuit.
Specification:
- Micro USB input: 5V 1A
- USB Output: 5V 2.1A / 5V 1A(Dual USB interface)
- Charging display: intelligent digital display
- Batteries Type: liquid lithium-ion batteries (18650)
Features:
- The motherboard comes with a protection function: Charging overcharge protection,
- over-discharge protection, overcurrent protection.
- Intelligent output device after charging full, automatically stops charging,
- to prevent mobile phones overcharged.
- Output voltage and current are stable, and will not harm user devices.
Installation Instruction:
The circuit board is connected to the battery negative B-, B + is positive, do not connect reversed, connecting reversed will burn the board, the battery is connected in parallel welding, assembling battery. Note that the insulation between the battery and the circuit board, battery lead not to touch the circuit board, so as not to cause a short circuit.
Package Included:
1 x Power Bank Module Dual USB with Display 5V 1A 2.1A Mobile Power Bank 18650 Battery Charger PCB Power Module
