Description:

The Arduino Portenta Hat Carrier is a robust and resilient carrier board, meticulously engineered to transform your Arduino Portenta board—be it the powerful X8, the versatile H7, or the efficient C33—into a full-fledged industrial single-board computer.

This innovative carrier acts as a crucial bridge, seamlessly connecting the powerful Portenta ecosystem with the vast world of Raspberry Pi Hats and cameras. This union opens up a new realm of possibilities for developing sophisticated commercial and industrial solutions, allowing you to leverage a massive library of existing add-ons and peripherals.

With the Portenta Hat Carrier, you gain immediate access to a comprehensive suite of essential interfaces. It features a CAN bus for robust in-vehicle or industrial networking, Ethernet connectivity (Gigabit with the X8, 100Mbit with H7/C33) for reliable data transfer, a convenient USB-A port, and a microSD card slot for critical data logging or system storage.

Engineered for both rapid prototyping and scalable, real-world deployments, this carrier board significantly expands the capabilities of the Portenta System on Modules. It integrates a 40-pin Raspberry Pi-compatible GPIO header, a dedicated MIPI CSI camera connector for intricate machine vision tasks, and 16 additional analog I/O pins for effortlessly interfacing with a wide range of sensors and actuators.

For developers seeking enhanced control and reliability, the board also includes dedicated JTAG pins for in-depth debugging and a PWM fan connector to actively manage thermal performance under even the most demanding workloads. This makes it an ideal choice for a diverse array of applications, including building automation, machine monitoring, and advanced robotics.

Specifications:

• Connectors:-
  • High-density connectors compatible with Portenta products
  • 1x USB-A female connector
  • 1x Gigabit Ethernet connector (RJ45)
  • 1x CAN FD with onboard transceiver
  • 1x MIPI Camera connector
  • 1x MicroSD card slot
  • 1x PWM fan connector
  • 40-pin header connector allowing compatibility with Raspberry Pi Hats
  • 16-pin analog header connectors, including:
    • 8x analog inputs
    • 1x GPIO
    • 1xUART without flow control
    • 2x PWM pins
    • 1x LICELL pin for Portenta's RTC power
• Interfaces:-
  • CAN FD
  • UART
  • SAI
  • ANALOG
  • GPIO
  • SPI
  • I2C
  • I2S
  • PWM

• Operating Temperatures:- -40° C to +85° C (-40° F to 185 °F)
• Debugging:- Onboard 10x pin 1.27mm JTAG connector

• Power:-
  • From onboard screw terminal block allowing:
    • 7-32V power supply, powering both the carrier and the connected Portenta
    • 5V power supply
  • From USB-C on Portenta
  • From 5V on 40 40-pin header connector

Features:

• Broad Compatibility: Works with Portenta X8, H7, and C33 modules and offers a standard 40-pin header for Raspberry Pi® HATs.
• Industrial Connectivity: Includes a high-speed CAN FD transceiver for robust industrial communication and an Ethernet port.
• Flexible I/O: Features a USB-A port for peripherals, a MicroSD card slot for data, and a MIPI CSI camera connector for machine vision.
• Expanded Functionality: Provides 16 additional analog I/O pins for sensors and actuators, along with a dedicated JTAG connector for easy debugging.
• Robust Design: Built with a wide operating temperature range (-40°C to +85°C) and a PWM fan connector for thermal management, making it ideal for robotics, industrial, and building automation projects.

 Package Included:

1 x Official Arduino Portenta Hat Carrier Development Board
