My Servo MB-2290SG Metal Gear Digital Servo 65.0kg High-Torque Servo For Demanding RC Models

My Servo MB-2290SG Metal Gear Digital Servo 65.0kg High-Torque Servo For Demanding RC Models

In stock

Rs. 8,199.00
Rs. 8,199.00
Sale Sold out
Shipping calculated at checkout.

Note: In case you receive a damaged or faulty product, please return it in the original box with all foam and packaging. Returns will not be accepted if further damage occurs due to improper packing.

For refund/return/replacement, call us at +91 95991 22209 or mail us at support@rees52.com

Delivery Time

  • Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.

  • Delivery time if the order item is on Preorder Status is 15-20 working days.

COD (Cash on Delivery)

  • For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
View full details

Description:

This high-performance servo offers incredibly precise control with a 3μs dead band, ensuring it responds instantly to your commands. It operates at a consistent 1520μs / 330Hz working frequency for smooth, accurate movement. At its core is a powerful brushless motor, which provides superior efficiency, higher torque, and a longer lifespan compared to traditional motors.

Specifications:

  • Dead band: 3μs
  • Working frequency: 1520μs / 330Hz
  • Motor: Brushless Moto
  • Operating Speed 7.4V): 0.13sec/60°
  • Operating Speed (8.4V): 0.11sec/60°
  • Stall Torque (7.4V):50.0kg cm
  • Stall Torque (8.4V): 65.0kg cm
  • Connector Wire Length: JR  265 mm
  • Bearing: 2BB
  • Output Gear Spline: 25T

Features:

  • Instant, Precise Control: A tiny 3μs dead band ensures the servo reacts instantly and accurately to every command.
  • Smooth Operation: Runs at a consistent 1520μs / 330Hz frequency for smooth, precise, and reliable movement.
  • Efficient Brushless Motor: A powerful brushless motor delivers superior torque, efficiency, and a longer lifespan.

Package Included:

1 x My Servo MB-2290SG High-Torque Metal Gear Digital Servo
