Description:
Multi Coin Acceptor Module have ability to identify genuine and fake coins according to the size of the coin, the material can identify the true and false coins. You can manually set the currency according to your needs, and the CPU will intelligently remember the currency you set.
Accept Multiple Currencies Set up to recognize 6 different coins to meet your currency diversification needs. The three-step pulse speed signal output, N.O. and N.C. output switch adjustments, has a wide range of application and can be modified as needed. The cumulative signal output and time control functions can be increased, and the coin acceptance prohibition function can be increased.
Specifications:
- Body Material: Plastic
- Panel Material: Zinc Alloy
- Power Supply: 12VDC±10%
- Working Current: 50mA
- Diameter of coins 15mm ~ 29mm
- Thickness of coins: 1.8mm ~ 3.0mm
- Recognition Rate: 95%
- Recognition Speed: 0.6 second
- Max Current: 350ma(<0.5S)
- Working Temperature -10-60℃
- Storage Temperature -20-85℃
- Working Humidity: ≤95%
- Atmospheric Pressure 85Kpa-106Kpa
Features:
-
Suitable for a variety of coins.
- Special precision/normal stall, smoother corners.
- Pulse output widths available.
- To prevent phishing and other ways of cheating, cheating alarm.
- Suitable for water dispensers, snack vending machines or game machines.
- CPU process control and accurate scoring.
Package Included:
1 x Multi Coin Acceptor Machine
