Description:
MPPT 5A Solar Panel Regulator is suitable for 9V 12V 18V 24V solar panels to the batteries,nickel-cadmium, lithium batteries (battery) charging, wind turbines solar street lamps. MPPT 5A Solar Panel Regulator input and output terminals are made of high-end switching power supply for high-frequency low-impedance electrolytic capacitors (LOW ESR), ensuring that the output ripples. MPPT 5A Solar Panel Regulator can effectively filter out the switching power supply glitches.
Specifications:
- The modular nature: a real MPPT solar maximum power point tracking, automatic intelligent charge management, low power consumption
- Input voltage: DC 8-28V input DC voltage. (prohibition AC input)
- Output voltage: DC 5-26V stepless transmission.
- 6V battery can be charged with either 12 or 8.4V/12.6V/16.8V lithium battery,7.2V/10.8V/14.4V lithium iron phosphate battery,2-4 string lithium batteries, and lithium iron phosphate charge management board.
- Output current: 2A/5A maximum charging current in two: A version 5A B version of A 2A 5A default shipping version
- Charge indicator: yes
- MPPT function: an MPPT maximum power point automatic tracking, to maximize the full use of solar charging
- Low pressure: 1V (as is the step-down voltage regulator, the input voltage is at least higher than the output 1V)
- Low power consumption: yes
- Operating temperature: industrial grade (-40 to +85 degrees)
- Load regulation: ± 1%
- Voltage regulation: ± 0.5%
- Conversion efficiency: Max 93% peak 95% for different lighting conditions vary.
- Charging: automatic intelligent three-stage charging mode. Self-tracking solar power charge current automatically adjusts the size
- No-load current: 3MA even weak morning sunlight can easily start automatically, eliminating the manual switch.
- Input reverse polarity protection: yes
- Output reflux protection: yes
- Connection: there terminals
Package Included:
1 x MPPT 5A Solar Panel Regulator Controller Battery Charging 9V 12V 24V Automatic Switch Solar Battery Charging Controller Panel 5A MPPT Solar Panel Regulator
