MCP2515 CAN-BUS Shield Board SPI Interface 9 Pins Standard Sub-D Connector Expansion Module For Arduino - NA250

MCP2515 CAN-BUS Shield Board SPI Interface 9 Pins Standard Sub-D Connector Expansion Module For Arduino - NA250

NA250

Low stock: 5 left

Rs. 669.00
Rs. 669.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94524 , +91 95995 94520 or mail us at support@rees52.com

Delivery Time

  • Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.

  • Delivery time if the order item is on Preorder Status is 15-20 working days.

COD (Cash on Delivery)

  • For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
View full details

Description:

CAN-BUS is a common industrial bus because of its long travel distance, medium communication speed, and high reliability. It is commonly found on modern machine tools and as an automotive diagnostic bus. This CAN-BUS Shield adopts an MCP2515 CAN Bus controller with an SPI interface and an MCP2551 CAN transceiver to give your Arduino/Seeeduino CAN-BUS capability. With an OBD-II converter cable added and the OBD-II library imported, you are ready to build an onboard diagnostic device or data logger.

Specifications:

  • Model Type: CAN Bus Shield
  • Default OBD Pinout: OBD-II Standard

Features:

  • Implements CAN V2.0B at up to 1 Mb/s
  • SPI Interface up to 10 MHz
  • Standard (11-bit) and extended (29-bit) data and remote frames
  • Two receive buffers with prioritized message storage
  • Industrial standard 9-pin sub-D connector
  • Two LED indicator

Applications:

  • Industrial control
  • Car control field

Useful Link:

 CAN-BUS Shield Board

Package Included:

1 x MCP2515 CAN-BUS Shield Board
