LED RGB 8x8 Matrix Driver - ATmega328 + DM163 - Iduino ST1149 - RS5043

LED RGB 8x8 Matrix Driver - ATmega328 + DM163 - Iduino ST1149 - RS5043

SKU:RS5043

Regular price Rs. 899.00
Regular price Sale price Rs. 899.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94524 For bulk and B2B enquiries kindly mail us at support@rees52.com

  • Fast Shipping
  • Affordable Price
  • Support
View full details

Description:

LED RGB 8x8 Matrix Driver Module with ATmega328 microcontroller and DM163 LED driver. Designed for 8x8 LED matrices LED RGB 8x8 Matrix Driver has three 8+6-bit channels for hardware PWM LED control. 8-bit colour support with 6-bit colour correction for each LED. LED RGB 8x8 Matrix Driver communicates via UART or I2C interface. The supply voltage of the module is 5V. The matrix cooperates with any microcontroller equipped with an I2C or UART interface, including Arduino. You can also use a UART converter to connect the module.

Specifications:

  • Microcontroller: ATmega328P
  • Driver: DM163
  • Number of LEDs: 64 (8 x 8)
  • LED color: RGB
  • Communication: UART or I2C
  • PWM: 16 MHz
  • 24 channels - 100 mA per channel
  • 8 channels - 500 mA per channel
  • Pinout for matrix connection: 46 mm
  • Dimensions: 65 x 60 mm

Features:

  • Hardware 16MHz PWM support
  • GPIO and ADC interface
  • 24 constant current channels of 100mA each
  • 8 super source driver channels of 500mA each
  • It has Hardware UART and IIC communication with easy cascading
  • 8bits colour support with 6bits correction for each color in every dot

Package Included:

1 x LED RGB 8x8 Matrix Driver - ATmega328 + DM163 - Iduino ST1149
