Description:
The L293D Motor Driver Shield is a versatile and easy-to-use motor control expansion board designed for Arduino UNO, Mega 2560, and compatible boards. Built around the reliable L293D dual H-bridge motor driver IC, this shield allows you to control multiple DC motors, stepper motors, and servo motors simultaneously, making it an ideal choice for robotics, smart cars, automation, and educational projects.
With support for up to 4 DC motors, 2 stepper motors, or 2 servo motors, the shield simplifies motor interfacing and eliminates complex wiring. It provides independent motor control with speed and direction management through PWM signals, enabling precise movement control for a wide range of applications.
Whether you're building a robotic vehicle, robotic arm, line follower robot, or automation system, the L293D Motor Driver Shield offers a cost-effective and reliable solution for driving motors directly from your Arduino board.
Specifications:
- Type: Motor Driver Shield
- Driver IC: L293D Dual H-Bridge Motor Driver
- Compatible Boards: Arduino UNO R3, Mega 2560, Duemilanove, Diecimila
- DC Motor Support: Up to 4 DC Motors
- Stepper Motor Support: Up to 2 Stepper Motors
- Servo Motor Support: Up to 2 Servo Motors
- Motor Supply Voltage: 4.5V – 25V DC
- Logic Voltage: 5V DC
- Output Current: 600mA per Channel (1.2A Peak)
- PWM Speed Control: Yes
- Direction Control: Forward / Reverse
- Motor Driver Type: Dual H-Bridge
- Interface Stackable Arduino Shields
- Communication: Arduino Digital Pins
- Protection: Back EMF Protection Diodes
- Mounting Type: Direct Arduino Shield Mount
Features:
- Drives up to 4 DC motors simultaneously
- Supports 2 stepper motors or 2 servo motors
- PWM-based speed control
- Easy plug-and-play shield design
- Compatible with popular Arduino development boards
- Ideal for robotics and motor control applications
Applications:
- Robotics
- Smart Cars
- Automation
- STEM Projects
- DIY Electronics
Package Included:
1 x L293D Motor Driver Shield For Arduino UNO Mega
