Description:
The iMAX B6 Charger is a very advanced charger, able to charge, balance and discharge LiIon, LiPoly, LiFe (A123), NiCd and NiMH batteries. iMAX B6 Charger is microprocessor controlled just like all the best chargers and will balance the individual cells in your Li-XX batteries.
iMAX B6 Charger will charge from 0.1 to 6.0A and is capable of charging packs up to 6S packs. iMAX B6 Charger features input voltage protection so as not to flatten your car battery in the field and will also store charge your pack for when you are not using them. You can power it with any power supply delivering from 11~18V so it is very flexible.
Specifications:
- Charge Current Range: 0.1~6A
- Maximum Discharge Power: 5W
- Discharge Current Range: 0.1~1.0A
- Drain Current for Balancing Li-Po's: 300aA/cell
- Li-ion/Po cell count: 1~6
- NiCd/NiMH cell count: 1 ~ 15 Cells
Features:
- Microprocessor controlled.
- Delta-peak sensitivity.
- Individual cell balancing.
- Li-ion, LiPo, and LiFe are capable.
- Ni-Cd and NiMH are capable.
- Large range of charge currents.
- Store function allows safe storage of current.
- Time limit function.
- Input voltage monitoring. (Protects car batteries at the field).
- Data storage (Store up to 5 packs in memory).
- Battery break-in and cycling.
