Description:
The Honeywell SS361CT Hall Effect/Magnetic Sensor offers reliable and accurate magnetic field detection. Its bipolar design operates on a low 4 mA supply current while providing a maximum output current of 20 mA.
This sensor is compatible with supply voltages from 4 V to 24 V, making it adaptable to various systems. It's built to withstand extreme temperatures, ensuring consistent performance from -40°C to 125°C.
The surface-mount (SMD/SMT) package allows for easy and efficient board mounting. With a wide operating point range of 5 G to 95 G, the SS361CT is well-suited for a broad spectrum of magnetic sensing applications, including position detection, speed sensing, and current sensing.
Specifications:
- Model Type: Magnetic Sensor
- Model No.: SS361CT
- Types: Bipolar
- Operating Voltage: 24V
- Operating supply current: 4 mA
- Maximum output current: 20 mA
- Operating point range: 5 G to 95 G
- Wide temperature range: -40°C to 125°C
Features:
- Bipolar Hall Effect design for accurate magnetic sensing.
- Temperature range of -40°C to 125°C for versatile applications.
- SMD/SMT mounting style for easy integration.
Application:
- Magnetic field detection in various devices
- Position and speed sensing in industrial machinery
- Motor control and fan operation
- Proximity sensing in electronic systems
- Measurement and monitoring in automotive and consumer electronics
Package Included:
1 x Honeywell SS361CT Surface Mount (SMT) Bi-polar Hall Effect Sensor for Reliable Board-Level Magnetic Switching
