FPV NEO-M8N GPS/Compass Naza M GPS/Compass Upgrade High-Performance GPS & Compass For DJI Naza M V1 and V2 Lite Flight Controller - RS4675

FPV NEO-M8N GPS/Compass Naza M GPS/Compass Upgrade High-Performance GPS & Compass For DJI Naza M V1 and V2 Lite Flight Controller - RS4675

RS4675

In stock

Rs. 1,925.00
Rs. 1,925.00
Sale Sold out
Shipping calculated at checkout.

Pickup available at REES52 OFFICE

Usually ready in 24 hours

For refund/return/replacement, call us at +91 95995 94524 , +91 95995 94520 or mail us at support@rees52.com

  • Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.

  • Delivery time if the order item is on Preorder Status is 15-20 working days.
  • For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
View full details

Description:

A new generation GPS NEO-M8N, with low power consumption and high precision, the ultimate accuracy is 0.6 meters, actually almost 0.9 meters, greater than the previous generation NEO-7N 1.4-1.6 meters accuracy, supports GPS/QZSS L1 C/A, GLONASS L10F, B1 protocol, and mode or more. Using 32-bit processor, compatible with V1 & V2 flight controller, incomparably superior to 8-bit processor.

Coming with a soft silicone gel cable of 30cm. For softness, black rubber was wrapped on a surface. (Notice: black cable= GND, white cable=TX, yellow cable=RX, red cable=5V, 3.3-7.5V is ok), Metal foil labels have been mounted on the bottom of GPS to reduce signal interference from other electronic types of equipment.

Specifications:

  • Item Type: GPS Module
  • Model: Ublox NEO 7M
  • Receiver Type: x
  • Receiver frequency: L1 [1575.42MHz]
  • Input Voltage (V): 3.5 to 5.5
  • Main Chip: U-BLOX NEO-7M
  • Position Accuracy (Meter): 2, 2.5
  • Acceleration (g): <4
  • Navigation Update Rate: 5Hz
  • Operating Temperature (°C): -24 to 84
  • Tracking Sensitivity (dBm): -161 dBm
  • Co-Ordinate System: WGS-84
  • Capture Time: 0.1s Average
  • Avg Cold Start Time (s): 38
  • Warm Start Time (s): 35
  • Boot Time: 1S
  • Maximum Altitude (m): 18000
  • Maximum Speed: 515 m/s

Features:

  • Locate performance
  • These are Pre-configured, Flashed with the correct settings, and tested. To make them Plug and Play.
  • Super Bright LED
  • Backplane with Standard Mk style mounting holes 45mm X 45mm
  • 38400 bps (Default) Changed to 115200bps!
  • Output GGA, GSA, and RMC frames
  • 1Hz (Default) Changed to 5Hz!
  • Permanent Configuration Retention
  • compass on board
  • 6 pin connector for EZ connects to MEGA BLACK
  • 4 pin connector for only GPS use
  • 4-pin connector for compass only use
  • Can use both 4 pins at once

Package Included:

1 x FPV NEO-M8N GPS amp Compass Support DJI Naza M V1 and V2 Lite Flight Controller
