Description:
The FNB58 USB tester is a high-reliability, high-safety USB voltage and current detection meter and a mobile communication terminal fast charging trigger. It has a 2.0-inch, full-color, ultra-wide viewing angle TFT LCD display, integrated USB-A, Micro-USB, and Type-C interface. Use external 16-bit ADC, PD protocol physical chip. It can be used to measure the power supply or power consumption of products such as USB interfaces, mobile phone chargers, and U disks; it can be used to measure the charging power of mobile phones and the input and output of mobile power supplies; it can be used to test the fast charging protocol of chargers.
Specifications:
|
Monitor Voltage
|
4~28V
|
|
Monitor Current
|
0~7A
|
|
Monitor Power
|
0~140W
|
|
D+/D- Voltage
|
0~3.3V
|
|
Load Equivalent Intemal Resistance
|
0~9999.9Ω
|
|
Equipment Temperature:
|
°C/°F
|
|
Capacity
|
0~9999.99Ah
|
|
Energy Used
|
0~9999.99Wh
|
|
Cable Resistance
|
0~9999.9Ω
|
|
Equipment Running Time
|
99days 23:59:59
|
|
Record Time
|
99days 23:59:59
|
Interface Description:
Package Included:
1 x FNIRSI FNB58 USB Fast Charge Tester
