Description:
The DSO510 is a high-performance flagship oscilloscope, perfect for complex signal testing, research, and development. Designed with advanced functionality, it’s ideal for professionals managing intricate repairs or educational environments needing precise measurements.
This oscilloscope offers a real-time sampling rate of 48MS/s and a 10MHz bandwidth, supporting both periodic analog and non-periodic digital signals. Equipped with complete trigger modes (Single, Normal, Auto), it provides reliable accuracy across a wide voltage measurement range of ±400V. The DSO510 also features an efficient one-click AUTO mode, displaying waveforms instantly without complicated adjustments.
Additionally, it includes a built-in signal generator with a 50KHz output capability, allowing for versatile testing setups. Its 2.8-inch HD LCD screen with 320×240 resolution ensures clear visuals, and the 1000mAh lithium battery offers up to 4 hours of continuous use.
This oscilloscope offers a real-time sampling rate of 48MS/s and a 10MHz bandwidth, supporting both periodic analog and non-periodic digital signals. Equipped with complete trigger modes (Single, Normal, Auto), it provides reliable accuracy across a wide voltage measurement range of ±400V. The DSO510 also features an efficient one-click AUTO mode, displaying waveforms instantly without complicated adjustments.
Additionally, it includes a built-in signal generator with a 50KHz output capability, allowing for versatile testing setups. Its 2.8-inch HD LCD screen with 320×240 resolution ensures clear visuals, and the 1000mAh lithium battery offers up to 4 hours of continuous use.
Basic Specifications:
|
Brand
|
FNIRSI
|
|
Model
|
DSO-510
|
|
Display
|
2.8 Inches / PPI:320*240
|
|
USB Charging
|
5V/1A
|
|
Lithium Battery Capacity
|
1000mAh
|
|
Size
|
99x68.3x19.5mm
|
|
Weight
|
104g
|
Mini Specifications:
|
Channel
|
1
|
|
Sampling Rate
|
48MS/s
|
|
Bandwidth
|
1MHz
|
|
Vertical Sensitivity
|
10mV/Div-20V/Div (Progress according to the 1-2-5 way)
|
|
Time Base Range
|
50ns/Div-20s/Div (Progress according to the 1-2-5 way)
|
|
Voltage Range
|
X1:±40V (Vpp:80V) X10:±400V (Vpp:800V) |
|
Trigger Mode
|
Auto / Normal / Single
|
|
Trigger Edge
|
Rising edge / Falling edge
|
| Coupling |
AC/DC
|
Signal Specifications:
|
Frequency
|
0-50KHz
|
|
Duty Cycle
|
0-100% (rectangular and sawtooth waves) |
|
Amplitude
|
0.1-3.0V
|
|
Waveforms
|
Sine wave, rectangular wave, sawtooth wave, half wave, full wave, step wave, anti step wave, exponential rise, exponential drop, DC signal, multi-tone, Sink pulse, Lorentz wave.
|
Features:
- Portable 2.8" TFT Handheld Oscilloscope for beginners, hobbyist
- DSO oscilloscope: 48MS/s, 10MHz bandwidth, ±400V voltage range.
- Signal Generator: 50KHz
- High-definition 320*240 LCD, Type-C interface.
- Finished assembly, lightweight, perfect for maintenance.
- Versatile trigger functions: single, normal, automatic.
- Signal Type Support: Periodic analog signals and non-periodic digital signals.
- 8 different languages: Chinese, English, Russian, Japanese, Spanish, Portuguese, German, Korean.
- One-Click AUTO Mode: Displays waveforms instantly without complex adjustments.
- Battery Life: Built-in 1000mAh lithium battery with 4 hours of use per charge.
- Recommended Use: Ideal for advanced repairs, development, and education projects.
Package Included:
- 1 x FNIRSI DSO-510 Handheld Digital Oscilloscope
- 1 x Packaging Box
- 1 x Alligator clip Probe
- 1 x Charging cable
- 1 x Lanyard
- 1 x Manual
- 1 x Adapter
- 1 x P6100 Probe
