Description:
FS-R7D is a light group receiver in compliance with the ANT protocol, providing 7 channels. It is equipped with a single antenna externally, supporting the 2-way transfer-back function. It can output PWM signals and light control signals, featuring the compact design. FS-R7D can be adapted to a variety of vehicle models.
Specifications:
- Product Model: FS-R7D
- Compatible Transmitters: FS-G7P(Surface transmitters with ANT protocol)
- Model Type: Cars
- PWM Channels: 7
- Numbers of Light Interface: 6
- RF: 2.4GHz ISM
- 2.4G Protocol: ANT
- Antenna: Single external antenna(Coaxial)
- Input Power: 3.5 ~ 9V /DC
- Working Current: 90mA(5V)
- Data Output: PWM/PPM
- Maximum Power: 20dBm (e.i.r.p.) (EU)
- Distance: 300m(Ground distance without interfence)
- Online Update: Yes
- Water Proof: PPX4
- Color: Black
- Temperature Range: -10℃ ~ +60℃
- Humidity Range: 20%~95%
Useful Link:
Package Included:
1 x Flysky FS-R7D Receiver
