Flange Mount BNC Connector 4 Hole Female Connector Solder Type - RS3645

Flange Mount BNC Connector 4 Hole Female Connector Solder Type - RS3645

SKU:RS3645

In stock

Regular price Rs. 137.00
Regular price Sale price Rs. 137.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94524 For bulk and B2B enquiries kindly mail us at support@rees52.com

  • Fast Shipping
  • Affordable Price
  • Support
View full details
  • Impedance : 50ohm
  • Frequency Range : 0~1 GHz for 75 ohm
  • VSWR : Straight type 1.22/3GHz / R/A type 1.30/3GHz
  • Dielectric Withstanding Voltage : 1500 V rms
  • Working Voltage : 500 V rms
  • Center Contact Resistance : 1.5 m (Milliohms max.)
  • Outer Contact Resistance : 2.0 m (Milliohms max.)
  • Insulation Resistance : 5 103 m (Milliohms min.)

Description :

These connectors are designed to terminate to industry-standard 50 ohm and 75-ohm cables with longer life, perfect designs and durable industry-grade Standards and finish.

Appliance:

Antennas, Cable Assembly, Automotive, Radios, Video, Broadcast, Telecom, Satcom, Monitors, Recorders, Switchers, Base Stations, Medical Equipment, Instrumentation, CCTV, CATV, HDTV, etc.

Features:

  • BNC Connector, Vertical Type, Female,180 Degree, Solder Type,4 Holes Flange,75Ohm, Nickel Plating
  • Compact Design for less installation space required
  • Easy quick connect and disconnect coupling

Electrical Characteristic :

  • Impedance : 50ohm
  • Frequency Range : 0~1 GHz for 75 ohm
  • VSWR : Straight type 1.22/3GHz / R/A type 1.30/3GHz
  • Dielectric Withstanding Voltage : 1500 V rms
  • Working Voltage : 500 V rms
  • Center Contact Resistance : 1.5 m (Milliohms max.)
  • Outer Contact Resistance : 2.0 m (Milliohms max.)
  • Insulation Resistance : 5 103 m (Milliohms min.)

Mechanical Characteristic

  • Coupling: bayonet
  • Contact Retention: 6 lbs min.
  • Mating Durability: 500 cycles

Environmental Characteristic

  • Environmental Characteristics:Teflon -55~+155 / POM -40~+60
  • Coupling Nut Retention: 100 lbs. min.
  • Vibration: MIL-STD-202 Meth. 204
  • Corrosion Resistance: MIL-STD-202 Meth. 101

Specification:

  • Brand : REES52
  • Orientation : Straight
  • Gender : Female
  • Mounting Type : Panel Mount / Cable
  • Termination Style : Solder Cup
  • Mounting Feature : 4 Hole Flange
  • Function : Other
  • Polarity : Standard
  • Body Material : Zinc Alloy
  • Body Plating : Nickel Plating
  • Impedance : 50/75 ohms
  • Shield Termination : Solder

Package Included:

1 x Flange Mount BNC Connector 4 Hole Female Connector Solder Type
