- The strongest version large-capacity flash-4m esp8266 serial wifi esp-14
- Wifi support wireless 802
- Support sta / ap / sta + ap three operating modes
- Built-in tcp / ip protocol stack to support multiple tcp client connections
- Built stm8003 microcontroller and serial communications esp8266
- ESP8266-14 is a low cost WIFI-MCU communication module
- The module is built with a powerful STM8003 Chip
- you can write STM8 Program by AT Command control ESP8266
Description:
ESP8266-14 It is a low-cost WIFI-MCU communication / Control module, built-in ESP8266 WIFI communication IC and STM8003 Single-chip, the industry's highly competitive package size and ultra-low power technology can be widely used in smart home networking and network field, For connecting the device to the user's physical Wi-Fi Wireless network for Internet or LAN communications, networked functions. The module is built with a powerful STM8003 Chips, all pins all pick out the serial port and its ESP8266 The serial port, you can write STM8 Program by AT Command control ESP8266 The realization of the vast majority of intelligent lighting and home WIFI Things functions.
Features:
- WIFI support wireless 802.11 b/g/n standards
- Support STA / AP / STA + AP three operating modes
- Built-in TCP / IP protocol stack to support multiple TCP Client connections
- Built STM8003 microcontroller and serial communications ESP8266
- Support UART / GPIO data communication interface
- Support Smart Link Smart Networking
- Remote firmware upgrade (OTA)
- Built-in 32-bit MCU, it can double as an application processor
- Voltage range of 2.8V ~ 3.6VDC, recommend using 3.3V single power supply
- STM8 MCU can be operated via AT commands most of IOT
Package Included:
1 x ESP8266 -14 Wifi Wireless Serial Ports Esp8266 Module for Arduino
