EMAX Nano Series ESC 20A BLHeli Oneshot125 3-4S for Fpv racing 250 - RS4995

EMAX Nano Series ESC 20A BLHeli Oneshot125 3-4S for Fpv racing 250 - RS4995

SKU:RS4995

Regular price Rs. 959.00
Regular price Sale price Rs. 959.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94524 For bulk and B2B enquiries kindly mail us at support@rees52.com

  • Fast Shipping
  • Affordable Price
  • Support
View full details
  • Support Oneshot125, active braking (damped light) (20A), with quick throttle response
  • Real 20A ESC, peak current up to 40A
  • Compatible with Skyline32, Naze32, Pixhawk, CC3D and other mainstream Flight Controllers

Description:

EMAX Nano Series ESCs are developed for racing multi-copters, based on BLHeli firmware and support OneShot125. They are compatible with Skyline32, Naze32, Pixhawk, CC3D and other mainstream Flight Controllers. They use authentic electronic components to ensure high quality and enhance the current endurance ability. Support Oneshot125, active braking (damped light) (20A), with quick throttle response. Real 20A ESC, peak current up to 40A. Compatible with Skyline32, Naze32, Pixhawk, CC3D and other mainstream Flight Controllers. Opto designed, with twisted pair wire for throttle signal line, strong anti-jamming capability. Support SimonK and BLHeli.

Specification:

  • Brand Name: EMAX
  • Item Name: Nano 20A ESC
  • BEC ESC: No Built-in BEC
  • Continuous Current: 20A
  • Burst Current(10s): 25A
  • Power Supply: 3-4S Lipo Battery
  • Programmable: Yes

Features:

  • Use authentic electronic components to ensure high quality and enhance the current endurance ability of the ESC.
  • Based on BLHeli firmware, it is optimized for high performance with excellent linearity and a much quicker throttle response.
  • Special designed for multi-rotors, and compatible with fixed-wing aircraft and helicopters.
  • Multiple protection features including Low-voltage cut-off protection / over-heat protection/throttle signal loss protection.
  • The throttle range can be configured and is fully compatible with all receivers, providing smooth, linear and precise throttle response.
  • All parameters, including default settings, can be programmed using a program card or a transmitter.

Package Included:

1 X EMAX Nano Series ESC 20A BLHeli Oneshot125 3-4S for Fpv racing 250
