DWIN

DWIN DMG80480C070_03WTR 7" HMI Display 800*480 Touchscreen HMI Panel DWIN HMI UART Serial Capacitive Touch Display Powerful 7" DWIN HMI Display For Enhanced Machine Control - RS6996

DWIN DMG80480C070_03WTR 7" HMI Display 800*480 Touchscreen HMI Panel DWIN HMI UART Serial Capacitive Touch Display Powerful 7" DWIN HMI Display For Enhanced Machine Control - RS6996

SKU:RS6996

Low stock: 1 left

Regular price Rs. 2,029.00
Regular price Sale price Rs. 2,029.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94524 For bulk and B2B enquiries kindly mail us at support@rees52.com

View full details

Description:

The DWIN DMG80480C070_03WTR is a 7-inch Human-Machine Interface (HMI) display designed for industrial applications. It features an 800x480 resolution TFT LCD screen with a resistive touchscreen, providing a clear and responsive interface for operator control and monitoring.

This model is an intelligent LCD module with a resistive touch screen for user interactivity.  It has onboard serial UART PORT which can be controlled by any microcontroller via a simple yet powerful command set. It can be used as a TFT Display & Touch controller in various electronic equipment such as vending machines, currency counting machines, washing machines, and many other similar appliances.

Function working principle

Specifications:

Model DMG80480C070_03WTR
LCD Type IPS TN Screen
Touch Panel Resistive Touch Panel
Resolution 800*480
Display Size 7 inches
Brightness 200nit
Interface UART
Operational Voltage 4.5V to 5.5V
Typical Current 150mA to 500mA


Features:

  • TTL/CMOS interface; 10Pin_1.0mm FCC connection wire.
  • Download via SD card or on-line serial port.
  • No touch screen/Resistive touch screen/Capacitive touch screen Optional.
  • Based on T5L1, running DGUS II system, commercial grade.
  • Dual Development System: DGUSⅡ/TA(Instruction set).
  • 7.0-inch, 800*480 pixels resolution, 16.7M colors, TN-TFT-LCD, normal viewing angle.
  • Normal viewing angle, 70°/70°/50°/70°(L/R/U/D).

8 PIN 2.0

Pin Description:

国际站PCB模板

Pin Description:

Package Included:

1 x DWIN DMG80480C070_03WTR HMI 7 Inch TN LCD Resistive Touch Display
