DWIN DMG19108C156_05WTC 15.6-inch Full HD HMI LCD Display with case, Capacitive Touchscreen and UART Interface 1920x1080 Commercial Grade LCD Display
DWIN DMG19108C156_05WTC 15.6-inch Full HD HMI LCD Display with case, Capacitive Touchscreen and UART Interface 1920x1080 Commercial Grade LCD Display
SKU:
In stock
Couldn't load pickup availability
- For Bulk Order Click Here
- Need Customer Support?
- Free Delivery Above 999/-
For refund/return/replacement, call us at +91 95995 94520 , +91 95991 22209 or mail us at support@rees52.com
Delivery Time
Delivery Time
- Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.
- Delivery time if the order item is on Preorder Status is 15-20 working days.
COD (Cash on Delivery)
COD (Cash on Delivery)
- For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
Description:
The DWIN DMG19108C156_05WTC is a 15.6-inch commercial-grade 2K HD HMI smart screen, engineered for high-performance industrial and smart automation applications. Powered by three T5L2 chips and running the advanced DGUS II GUI development system, this display offers exceptional responsiveness, customization, and stability.
Its 15.6-inch IPS LCD panel delivers crisp 1920x1080 resolution with wide viewing angles, providing a vivid and immersive 2K HD visual experience — ideal for modern user interfaces, dashboards, kiosks, and control panels.
Designed with flexibility and integration in mind, it features a capacitive touch interface, onboard buzzer, RTC (Real-Time Clock), and a speaker interface. The UART2 communication port supports dual-mode switching: TTL/CMOS when ON, and RS232 when OFF — allowing seamless compatibility with a wide range of systems.
Whether used in industrial automation, smart terminals, or advanced IoT solutions, this smart screen combines power, clarity, and connectivity in one sleek, robust module.
Specification:
- Display Size: 15.6 inches
- Resolution: 1920x1080
- Display Panel: IPS, TFT LCD
- Touch Type: Capacitive
- View Angle: Wide viewing angle, 85Deg/85Deg/85Deg/85Deg (L/R/U/D)
- Color: 24-bit 8R8G8B
- Display Area: 343.2mm (W) x 192.6mm (H)
- Power Supply: 12~36V
- Brightness: 250nit
- Interface: TTL
Features:
- Based on three T5L2 chips, running DGUS II system, commercial grade
- Onboard buzzer, RTC, and speaker interface
- 15.6-inch display with a resolution of 1920*1080 pixels
- IPS wide viewing angle for optimal visibility
- UART2: ON=TTL/CMOS; OFF=RS232 for flexible communication
- Support FSK camera function (Customization required for adding FSK camera interface)
- Support audio and video playback
Useful Link:
DWIN DMG19108C156_05WTC 15.6-Inch 1920x1080 HMI LCD Touch Display
Package Included:
1 x DWIN DMG19108C156_05WTC 15.6-Inch 1920x1080 HMI LCD Touch Display With case
