Description:
The DC Voltage Regulator Buck Converter is a versatile and efficient power supply solution for various applications. With an input voltage range of 6-36V, it can convert and regulate the output voltage from 1.25-32V, making it suitable for charging batteries, powering electronic devices, or serving as a car power supply. Featuring a constant current of 5A, this converter ensures stable and reliable power delivery. The built-in MPPT (Maximum Power Point Tracking) solar controller optimizes energy harvesting from solar panels, maximizing efficiency and charging performance.
The integrated LED voltmeter, ammeter, and power display provide real-time monitoring of voltage, current, and power consumption, allowing for precise control and management. Compact and durable, this buck converter is an ideal choice for off-grid applications, solar energy systems, automotive electronics, and various DIY projects. With its wide input and output voltage ranges, constant current capability, and advanced features like MPPT and power monitoring, this device offers a versatile and efficient power management solution.
Specifications:
- Input voltage: 6-36V
- Output voltage:1.25-32V continuously adjustable (default 5V)
- MPPT voltage setting range: 6-36V
- Output current range: 0.05-5A (default 3A)
- Turn lights output range: 0.01-5A (default 0.3A)
- Operating temperature: -40 to + 85 degrees
- Operating frequency: 180KHz
- Conversion efficiency: up to 95% (efficiency is related with input voltate,output voltage,current and voltage difference)
- Short circuit protection: Yes
Features:
- 5A constant current and voltage non-isolated buck module, compact design, small size and high conversion efficiency, up to 95%.
- Has turn light control and charge indicator: red light on when charging, green light on when full charging, convenient to observe the state of charge.
- With LED voltmeter, press the button for 3 seconds to switch among input/output voltage and output current and output power; press for 5 seconds to turn on/off the voltmeter.
- With MTTP control, the setting range is 6-36V; Effectively shorten the time when charge battery by solar panel, the constant current function effectively protect battery from over-charging.
- With short circuit and over temperature protection; Can be used to drive large power LED, charge battery, as a vehicle power supply to charge mobile phone or a variety of digital products, etc.
Note:
- The current detection module is the low-end testing, please do not directly connect the input negative with the output negative!
Package Included:
1 x DC Voltage Regulator Buck Converter 6-36V to 1.25-32V Constant Current Voltage MPPT Solar Charge Controller 5A Solar Panel Power Supply With LED Display Voltmeter Ammeter Power Display For Charging Battery Car Power Supply
