Description:
6-60V 30A Motor Speed Controller is mainly used for controlling the DC motor speed. Motor Speed Controller is made of high-quality material, with a long serving life. Digital display Panel design, easy for reading and operating. 6-60V 30A Motor Speed Controller can set the time of DC Motor Slow Start and Stop, easy to operate.
Specifications:
- Input Voltage: DC 6-60V
- Output Voltage: linear underload
- Output Current: 0-30A
- Continuous Current: within 20A
- Speed Regulation Type: flow regulation
- Speed Control Mode: Jog +-
- Speed Adjustment Range: 0-100%
- Control Frequency: 21kHz
- Wiring Type: barrier terminal block
- Supported Motor: brush motor
- Speed Digital Display: 0-100%
Features:
- Soft start time setting: 000-100, slow start to 100% speed time is adjustable between 0-10 seconds, the default is 1 second.
- Soft stop time setting: 000-100, slow stop time is adjustable between 0-10 seconds, the default is 1 second.
- Rotation speed lower limit setting: 000-080, the minimum speed is adjustable between 0-80%, and is less than the maximum speed setting value, the default is 0.
- Speed limit setting: 000-100, the maximum speed is adjustable between 0-100% and is greater than the minimum speed setting value, the default is 100%.
- Acceleration and deceleration value setting: 001 002 005 010 015 020 025 Each time you press the plus and minus key, the speed changes accordingly by 1%, 2%, 5%, 10%, 15%, 20%, 25%.
Package Included:
1 x DC Motor Controller
