Description:

This is normally open interface maximum load: AC 250V/10A, DC 30V/10A. SMD optocoupler isolation, strong driving capability, stable performance; trigger current 5mA. Fault-tolerant design, the relay will not move even if the control line is broken. Power indicator (green), relay status indicator (red). The interface is designed humanized, and all the interfaces can be directly connected by wiring terminals, which is very convenient.

Specification:

  • Relay version: 24V
  • Quiescent current: 5mA
  • Maximum current: 50mA
  • Trigger current: 2-4mA
  • Trigger voltage (low level): 0-8V
  • Trigger voltage (high level): 8.5-24V
  • High and low trigger select side: 1.S1 for 1-Channel relay high and low trigger selection

Features:

  • 3.COM and LOW connection,
  • the corresponding relay is low-level trigger,
  • COM and HIGH-side connection is high when the trigger.

Module Interface:

  • DC +: then the power supply positive (voltage according to the relay requirements, with 5V.12V and 24V choice); 2, DC-: connected to the power supply negative;
  • IN1: 1 signal trigger side, you can set the high or low level control relay pull; 1, NO1: 1 relay normally open interface; 2, COM1: 1 relay common interface;
  • NC1: 1 relay normally closed interface;

Relay outputs:

  • NO: Normally open relay interface, the relay before the vacant after the pull shorted with COM;
  • COM: Common Interface Relays;
  • NC: Normally closed relay interface relay shorted with COM ago , after the pull- vacant.

Meaning of High level and Low-level:

  • High-level trigger refers to using the anode voltage at the VCC connection way of a trigger and triggers the end when the trigger side has the positive voltage or to trigger voltage when the relay is off.
  • Low-level trigger refers to using the negative voltage at the GND connection way of a trigger and triggers the end when the trigger side has 0 v low voltage or voltage to can trigger, the relay is off.

Package Included:

1 x DC 24V 1 Channel Relay Module 30A With Optocoupler Isolation Support High-level Low-level Triggered
