Description:
Cyclone 45A ESC a premium 6-layer, 3-ounce copper-thick PCB is used; to improve anti-jamming performance, a layered layout with a big current and a small control signal is used. The PCB surface’s gold plating procedure can significantly increase the electric regulation’s capacity to dissipate heat and withstand current. With its built-in RGB multi-color LED night light, night flying is even more spectacular. It is compatible with DShot 150/300/600 digital throttle and BLHeli-S. It responds quickly and has a great anti-jamming capability. The hardware PWM operates the motor by default, with the Damped Light hardware PWM activated. The throttle response is smoother and there is less noise. Motor deceleration is more responsive and efficient when using the damped light mode and regenerative braking feature.
Specifications:
- Item Type: Brushless ESC
- Output Voltage(V): Support 2-6S power supply
- Working Current: 35A
- Supported protocols: dshot 125/300/600
- Power cord length: 18AWG 90mm
- Signal line length: 150 mm
Features:
- Gold plated PCB
- Regenerative braking function
- Strong anti-jamming ability and quick response.
Package Included:
1 x Cyclone 45A ESC BLHeli_S 2-6S Lipo Brus ESC Electronic SED Controller Built-in Programmable RGB LED For RC FPV Drone Quadcopter
