CC-DEBUGGER - Programmer for RF Sys-on-Chips - RS3326

CC-DEBUGGER - Programmer for RF Sys-on-Chips - RS3326

SKU:RS3326

Low stock: 5 left

Regular price Rs. 1,044.00
Regular price Sale price Rs. 1,044.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94524 For bulk and B2B enquiries kindly mail us at support@rees52.com

  • Fast Shipping
  • Affordable Price
  • Support
View full details
  • Minimum Target Voltage : 1.2V
  • Maximum Target Voltage : 3.6V
  • Operating Temperature : 0C to 85C
  • Regulated Voltage on CC Debugger : 3.3V
  • Maximum Target Current : 200mA

Description :

The CC Debugger is a small programmer and debugger for the TI Low Power RF System-on-Chips. It can be used together with IAR Embedded Workbench for 8051 (version 7.51A or later) for debugging and SmartRF Flash Programmer for flash programming. The CC Debugger can also be used for controlling selected devices from SmartRF Studio.

Features:


1. CC-Debugger can be used to program and debug the following 8051-based system-on-chips from Texas Instruments:

  • CC1110, CC1111
  • CC2430, CC2431
  • CC2510, CC2511
  • CC2530, CC2531, CC2533
  • CC2540, CC2541
  • CC2543, CC2544, CC2545

2. It is possible to control the same devices from SmartRF Studio. In addition, CC-Debugger can control the following transceivers from SmartRF Studio:

  • CC1120, CC1121, CC1125, CC1175
  • CC1100, CC1101, CC110L, CC113L, CC115L
  • CC2500, CC2520

3. It can also be used to program the PurePath Wireless devices:

  • CC8520, CC8521
  • CC8530, CC8531

Specification :

  • Minimum Target Voltage : 1.2V
  • Maximum Target Voltage : 3.6V
  • Operating Temperature : 0C to 85C
  • Regulated Voltage on CC Debugger : 3.3V
  • Maximum Target Current : 200mA

Supported Operating Systems :

  • Windows 7
  • Windows 8
  • Windows XP SP2/SP3
  • Windows 2000

Package Included:

  • 1 x CC Debugger
  • 1 x USB cable
  • 1 x 10Pins flat cable
