- Operating Voltage : 3.3 ~ 5.5 VDC
- Output Voltage : 0 ~ 3.0VDC
- Operating Current : 5mA
- Interface : PH2.54-3P
Description:
This capacitive soil moisture sensor V2.0 measures soil moisture levels by capacitive sensing rather than resistive sensing like other sensors on the market. It is made of corrosion-resistant material which gives it excellent service life. Insert it into the soil around your plants and impress your friends with real-time soil moisture data!
This module includes an onboard voltage regulator which gives it an operating voltage range of 3.3 ~ 5.5V. It is perfect for low-voltage MCUs, both 3.3V, and 5V. For compatibility with a Raspberry Pi, it will need an ADC converter.
This soil moisture sensor is compatible with our 3-pin Gravity interface, we can connect to the Gravity I/O expansion shield.
Features:
- Supports 3-Pin Gravity Sensor interface
- Analogue output
Applications:
- Garden plants
- Moisture detection
- Intelligent agriculture
Additional information:
- Operating Voltage: 3.3 ~ 5.5 VDC
- Output Voltage : 0 ~ 3.0VDC
- Operating Current: 5mA
- Interface: PH2.54-3P
Package Included:
1 x Capacitive Soil Moisture Sensor V2.0
