Description:
BLHeli-S is the latest protocol for high-performance ESC. BLHeli_S 30A ESC offers high-frequency response and fast motor control for drone racing and competition. Can also be easily programmed to output different protocols- Muted mode, Oneshot125, Oneshot42 Multishot, and DSHOT. In addition to offering enhanced capabilities such as reversing and often, telemetry, BLHeli_S 30A ESC can have its parameters and features programmed through the flight controller while it is connected to a PC (if the autopilot firmware provides this capability also).
This BLHeli_S 30A ESC pass-through protocol allows you to configure and upgrade your ESCs without having to disconnect them from your vehicle. You can plug a USB cable into your autopilot and run the BLHeli Suite or BLHeliSuite32 software for Windows to configure your ESCs. Most BLHeli ESCs can autodetect if PWM or DShot is selected by the motor protocol parameter set by the user. See the configuration section of DShot Protocol ESCs for more information.
Specifications:
- Input Voltage: 2-4S LiPo
- Continue Current: 30A
- Burst Current: 35A up to 10s
- Firmware: BLHeli-S firmware
- Function: DSHOT150/300/600/ONESHOT
Features:
- High-speed drive IC, smooth start, and quick response.
- BLHeli_S 30A ESC supports a high KV motor to start quickly, violent flight.
- Exposed PCB solder joints. Solder directly to the motor wire. Connect firmly.
- The volume is mini and the weight is light. It makes the installation more convenient and the flight is more sensitive.
Package Included:
1 x BLHeli_S 30A ESC OPTO 2-4S Brushless Speed Controller ESC Supports Mulitshot Oneshot42 OneShot125 For RC FPV Drone Quadcopter Toy
