Description:
The Benewake TF-SV24S08 is an advanced single-point LiDAR relay module that operates on the Time of Flight (ToF) principle. This cutting-edge LiDAR sensor utilizes a unique optical and electrical design to deliver highly accurate, stable, and sensitive distance measurements. Its compact size, lightweight build, and low power consumption make it ideal for integration into a wide variety of systems.
The module is equipped with built-in adaptive algorithms, enabling it to perform reliably across diverse application environments and with different types of targets. Whether for industrial, robotic, or automotive use, the TF-SV24S08 ensures precision and versatility in its distance-sensing capabilities.
Specifications:
- Field of View (FOV): 2Deg.
- Supply Voltage (V): 8-36V
- Accuracy: -+6cm%@(0.2m-3m);+-2%@(3m-8m)
- Frame Rate(Hz): 1-250Hz (adjustable)
- Average Current(mA): 30mA
- Peak Current (mA): 150mA
- Operating Temperature (°C): -10~60℃
- Color: Black
Features
- Tiny Size.
- High accuracy.
- Low power consumption.
- Distance ranges up to 8 Meters.
Applications:
- Parking system.
- Machine security.
- Intrusion detection.
- Any switching application.
Package Included:
1 X Benewake TF-SV24S08 Lidar Sensor Ranging Module High-Resolution Lidar Range Finder For Precise Distance Measurement
