Description:
The ADP800 sensor family represents Aosong's commitment to delivering high-performance, cost-effective digital differential pressure sensors tailored to the demands of high-volume applications. These sensors are meticulously engineered to accurately measure the pressure of air and non-aggressive gases, providing critical data with exceptional precision and long-term stability. The ADP800 series distinguishes itself by its ability to eliminate offset drift, a common challenge in pressure sensing, ensuring reliable and consistent readings over extended periods.
Designed to cater to a broad range of applications, the ADP800 sensors cover a pressure range of up to ±500 Pa (equivalent to ±2 inches of H2O or ±5 millibars). This range allows for versatility in various settings, from HVAC systems and medical devices to industrial automation. Notably, these sensors maintain outstanding accuracy even at the lower end of the measuring range, where precision is often most critical. This capability ensures that subtle pressure variations are captured with confidence, enabling fine-grained control and monitoring.
Specifications:
- Measurement Range: -500 to 500 Pa (-2 to 2 inH2O)
- Stability: 0.05 Pa/year Offset
- Resolution (Bits): 24 bit
- Compatibility: Air, N2, O2, non-condensing (media compatibility)
- Additional Specs: Span repeatability: 3 0.5% of reading, Zero point repeatability: 3 0.1 Pa
Features:
- Precise Stable: Excellent repeatability, zero drift/offset, and long-term stability.
- Enhanced Performance: Smart averaging for improved signal quality and best signal-to-noise ratio.
- Ready for Use: Calibrated and temperature compensated for immediate, accurate readings.
- Reliable Proven: Industry-proven technology with a long track record and high reliability.
- Mass Production Ready: Designed for efficient mass production with high process capability.
Package Included:
1 x ASAIR ADP810 Differential Pressure Sensor
