Description:
AM2305 Digital Temperature & Humidity Sensor is a temperature and humidity combined sensor been calibrated digital signal output. The sensor includes a capacitive sensor wet components and a DS18B20 temperature measurement device and connected with a high-performance 8-bit microcontroller. Each AM2305 sensors are an extremely accurate humidity calibration chamber for calibration. Calibration coefficients stored in the form of a program in OTP memory, internal sensor detection signal processing to call these calibration coefficients. The single-wire serial interface, system integration becomes simpler and quicker. Ultra-small size, low power consumption, signal transmission distance up to 20 meters or more, making it the best choice of even the most demanding applications in a variety of applications then, the product leads to three core shielded cables.
Specifications:
| Voltage Rating |
5V |
| Measuring Range |
-40~80℃ |
| Interface |
Digital |
| Temperature Range |
-40~80℃ |
| Accuracy |
±0.3℃;±3%RH |
| Features |
Metal screen/capacitance sensor |
| Sensor Type |
AHT10 integration sensor |
| Output |
Digital Sensor, Digital 1 Wire |
| Humidity Range |
0~99.9%RH |
Features:
- The product has excellent quality
- Fast response
- Anti-interference ability
- Ultra-small size
- Low power consumption
Applications:
- Environmental monitoring
- Ventilator / respirator
- Anesthesia machine
- Spraying machine
- Medical apparatus and instruments
- The automatic control
- Experimental apparatus
Package Included:
1 x AM2305 Digital Temperature & Humidity Sensor High-Precision & Accurate Humidity And Temperature Transmitter Sensor
