Description:
The AI Thinker AiPi-Eyes-S2 is a versatile AI development platform with an integrated camera, microphone, and speaker. Powered by a robust AI processor, it supports real-time video and audio processing. The device’s compact design includes Wi-Fi and Bluetooth connectivity for seamless communication. With modular features and compatibility with major AI frameworks, it serves as an excellent choice for developers working on projects in computer vision, speech recognition, and IoT applications.
Specifications:
- Model: AiPi-Eyes-S2
- Product type: open-source hardware
- Chip: BL618(Ai-M61-32S module)
- Module: Ai-M61-32S
- Display: 3.5inch
Features:
- WIFI6+BLE5.3+Thread
- Support IEEE 802.11 b/g/n/ax protocol
- Wi-Fi security support WPS/WEP/WPA/WPA2/WPA3
- Support 20/40MHz bandwidth, 1T1R，Maximum rate 229.4 Mbps
- Support STA, SoftAP, STA+SoftAP and sniffer mode
- Dual-core 32-bit RISC-V CPU with FPU and DSP, the highest frequency can reach 320M
- 532KB SRAM,128KB ROM, 4Kb eFuse
- Integrated RF Balun, PA/LNA
- Support XIP QSPI On-The-Fly AES Decryption (OTFAD)
- Aipi-Eyes-S2 support TrustZone
- Support AES-CBC/CCM/GCM/XTS mode
- Support MD5, SHA-1/224/256/384/512
- Support TRNG (true random number generator)
- Support for PKA (Public Key Accelerator) for RSA/ECC
- Support Wi-Fi Quick Connect with BLE
- General AT commands can be used conveniently
- Support secondary development, Windows, Linux environment
Package Included:
1 x Ai-Thinker Aipi-Eyes-S2 Development Board
