Description:
AiPi-Eyes-DU uses an Ai-Thinker M61 module as the control core and uses a Type-C interface for the power supply. The Ai-M61-32S module equipped has rich peripheral interfaces, including DVP, MJPEG, Display, AudioCodec, USB2.0, SDU, Ethernet (EMAC), SD/MMC (SDH), SPI, UART, I2C, I2S, PWM, GPDAC, GPADC, ACOMP, GPIO, etc.
Specifications:
- Model: AiPi-Eyes-DU
- Product Type: open-source hardware
- Module: Ai-M61-32S
- Chip: BL618(Ai-M61-32S module)
Features:
- WIFI6+BLE5.3+Thread
- AiPi-Eyes-DU support IEEE 802.11 b/g/n/ax protocol
- Wi-Fi security support WPS/WEP/WPA/WPA2/WPA3
- Support 20/40MHz bandwidth, 1T1R，Maximum rate 229.4 Mbps
- Support STA, SoftAP, STA+SoftAP and sniffer mode
- Dual-core 32-bit RISC-V CPU with FPU and DSP, the highest frequency can reach 320M
- 532KB SRAM, 128KB ROM, 4Kb eFuse
- Integrated RF Balun, PA/LNA
- Support XIP QSPI On-The-Fly AES Decryption (OTFAD)
- Support TrustZone
- Support AES-CBC/CCM/GCM/XTS mode
- Support MD5 SHA-1/224/256/384/512
- Support TRNG (true random number generator)
- Support for PKA (Public Key Accelerator) for RSA/ECC
- Support Wi-Fi Quick Connect with BLE
- General AT commands can be used convenient
- Support secondary development, Windows, Linux environment
Package Included:
1 x Ai-Thinker AiPi-Eyes-DU with Camera
