AD8367 Variable Gain Amplifier With 500MHz Bandwidth maximum gain of 42dB can also be achieved, the maximum gain test of the small signal of the spectrum analyzer: (input power: -40dB) Remarks: Because AD8367 is a VCA chip that is prone to self-excitation, in actual use, due to the influence of capacitance resistance tolerance and board layout, the AD8367 is prone to self-excitation when it exceeds or approaches the maximum control voltage of 1.2V.
Adjustable Gain Amplifier is impossible to see the dominant frequency signal with an oscilloscope. Only a vector network analyzer and a spectrum analyzer can see the maximum gain of the AD8367 of 42dB.
Specifications:
-
Product model: AD8367 variable gain amplifier
- Supply voltage range: ±5V
- Product model: AD8367 variable gain amplifier
- Product size: 45x28mm
- Supply voltage range: ±5V
- Input power: -50dBm
Features:
- Suitable for mid-range amplification, and signal amplification within 300MHz.
- excellent in-band flatness with high gain.
Pin Description:
Package Included:
1 x AD8367 Variable Gain Amplifier Module
